8
Engine displacement ................................................................................................................................................... 25.4cc
Maximum engine performance .................................................................................................................................... 0.9kW
Cultivating depth .........................................................................................................................................................19.8cm
Tine diameter ................................................................................................................................................................. 20cm
Tine speed ............................................................................................................................................................... 254RPM
Tilling width ................................................................................................................................................................ 25.8cm
Net weight ....................................................................................................................................................................13.6kg
( Fig 1).
Before attempting to use this product, familiarize yourself
with all operating features and safety rules.
The engine switch (2) controls the ignition system. The switch
must be in the ON ( ) position for the engine to start and run.
To stop, place the switch in the OFF ( ) position.
Putting sand in the sand tank allows greater stability when
operating the cultivator, and also gives added weight to the
machine, allowing it to cultivate with less effort and vibration.
The recoil starter (3) is used for starting the engine.
The primer bulb (7) pumps fuel from the fuel tank to the
carburetor. This is necessary only when starting a cold engine
or after refueling an engine that has run out of fuel.
The start lever (4) opens and closes the choke valve in the
carburetor. The position enriches the fuel mixture
for starting a cold engine. The position provides the
correct fuel mixture for normal operation after starting, or for
restarting a warm engine.
The throttle lever (1) controls the rotation speed of the tines.
Completely engage the throttle lever while cultivating.
If any parts are missing do not operate this tool until the
missing parts are replaced. Failure to heed this warning
could result in possible serious personal injury.
Do not attempt to modify this tool or create accessories not
recommended for use with this tool. Any such alteration
or modication is misuse and could result in a hazardous
condition leading to possible serious personal injury.
To prevent accidental starting that could cause serious
personal injury, always disconnect the engine spark plug
wire from the spark plug when assembling parts.
( Fig 2 ).
n Loosen the two handlebar knobs (14) .
n Unfold the handlebar (13) into operating position.
Do not use force. If there is binding, continue to
loosen the knobs. Do not allow throttle cable to become
pinched when raising the handlebar.
This product requires assembly.
n Carefully remove the tool and any accessories from the
box. Make sure that all items listed in the packing list are
included.
n Inspect the tool carefully to make sure no breakage or
damage occurred during shipping.
n Do not discard the packing material until you have carefully
inspected and satisfactorily operated the tool.
Cultivator
Drag Bar
Pull Pin
Hitch Pins (2)
Felt Washers (2)
Inner Tines (2)
Outer Tines (2)
Ryobi Exact Mix 2-stroke Oil
Wheel Assembly (Accessory)
Operator’s Manual
