■ Replace the Engine cover. Reinstall screws and

secure.

■ Replace the chain brake on the post.

  Check to ensure that the air filter is in the

proper position before reinstalling the Engine cover.

If you notice a power loss with the petrol powered

tool, the exhaust port and Silencer may be blocked

with carbon deposits. These deposits may need to be

removed to restore performance. We highly recommend

that only qualified service technicians perform this

service.



See Figure 65.

Check the fuel filter periodically. Replace it if

contaminated or damaged.



See Figure 66.

This engine uses a Champion RCJ4 or RCJ6Y or NGK

BPMR7A with .025 in. electrode gap. Use an exact

replacement and replace every 50 hours or more

frequently, if necessary.

■ Remove the spark plug lead, by carefully rotating

back and forth whilst gently pulling upwards

■ Loosen the spark plug by turning it counter clockwise

with a wrench.

■ Remove the spark plug.

Hand thread the new spark plug, turning it clockwise.

Tighten securely with wrench.

 Be careful not to cross-thread the spark plug.

Cross-threading will seriously damage the Engine.

■ Re-attach the spark plug lead by pressing firmly onto

top of spark plug

   

SCREEN

See Figure 67.

The Silencer is equipped with a spark arrestor screen.

A faulty spark arrestor screen can create a fire hazard.

Through normal use the screen can become dirty and

should be inspected weekly and cleaned as required.

Always keep the Silencer and spark arrestor on the saw

in good condition.



Silencer surfaces are very hot during and after

operation of the chainsaw. To avoid serious

personal injury, keep all body parts away from

the Silencer.

■ Allow the Silencer to cool.

■ Remove the deflector retaining nut.

■ Remove the deflector to access the spark arrestor

screen and gasket.

■ If dirty, clean the spark arrestor screen with a small

wire brush. Replace the screen if it is cracked or

otherwise deteriorated. To obtain a replacement spark

arrestor, contact your Ryobi service centre.



See Figure 68.

■ Always keep the chain brake mechanism clean by

lightly brushing the linkage free from dirt

■ Always test the chain brake performance after

cleaning. Refer to    for

additional information.



Even with daily cleaning of the mechanism, the

dependability of a chain brake to perform under

field conditions cannot be certified.



■ Clean all foreign material from the product. Store it in

a well-ventilated place that is inaccessible to children.

Keep away from corrosive agents such as garden

chemicals and de-icing salts.

■ Observe local regulations for the safe storage and

handling of petrol.



■ Drain all fuel from tank into a container approved for

petrol.

■ Run the engine until it stops. This will remove all

fuel-lubricant mix that could become stale and leave

varnish and gum in the fuel system.

■ Squeeze primer bulb several times to purge fuel from

carburettor.

■ Drain all bar and chain lubricant from tank into a

container approved for lubricant.

■ Always place the scabbard over the guide bar and

chain before transporting or storing the unit.





Fuel mixture level . . . . . . . . . . . . . . . . . . . . . Before each use

Bar lubrication . . . . . . . . . . . . . . . . . . . . . . . . Before each use

Chain tension. . . . . . . . . . . . . . . . . . . . . . . . . Before each use

Chain sharpness . . . . . . . . . . . . . . . . . . . . . . Before each use

For damaged parts . . . . . . . . . . . . . . . . . . . . Before each use

For loose fasteners . . . . . . . . . . . . . . . . . . . . Before each use

For loose parts. . . . . . . . . . . . . . . . . . . . . . . . Before each use

Chain brake function . . . . . . . . . . . . . . . . . . . Before each use

For fuel leaks. . . . . . . . . . . . . . . . . . . . . . . . . Before each use



Bar . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Before each use

Complete saw . . . . . . . . . . . . . . . . . . . . . . . . . . After each use

Air filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .Every 5 hours*

Chain brake . . . . . . . . . . . . . . . . . . . . . . . . . . . .Every 5 hours*

. . . . . . . . . . . . . . . . . . . . . . . . . . . . Yearly

 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . Yearly

* Hours of Operation
