7
ADJUSTING THE CHAIN TENSION
See page 23.
1. Loosen the chain tensioner knob slightly by turning it
counterclockwise.
2. Check the chain tension frequently while adjusting. To
increase the chain tension, turn the chain tensioner
adjustment ring clockwise. To reduce the chain
tension, turn the chain tensioner adjustment ring
counterclockwise.
3. The chain tension is correct when the gap between the
cutter in the chain and the bar is between 3 mm - 4
mm. Pull the chain in the middle of the lower side of the
bar downwards (away from the bar) and measure the
distance between the bar and the chain cutters.
4. Tighten the chain tensioner knob by turning it clockwise.
ADDING CHAIN LUBRICATING OIL
See page 13.
WARNING
Never work without chain lubricant. If the saw chain is
running without lubricant, guide bar and saw chain can
be damaged. It is therefore essential to check the oil
level in the oil level gauge frequently and every time
before starting to use the chain saw.
1. Clear surface around the oil cap to prevent
contamination.
2. Remove the cap from the oil tank.
3. Pour the oil into the oil tank and monitor the oil level
gauge. Ensure that no dirt enters the oil tank while
filling.
4. Close the oil tank and tighten the cap. Wipe away any
spillage.
5. One full oil tank enables you to use the saw for 9-30
min.
Recommended chain lubricating oil
■ The manufacturer recommends to use only RYOBI
chainsaw lubricating oil. (Available from Bunnings
stores)
INSTALLING BATTERY PACK
See page 13.
1. Place the battery pack in the chain saw. Align raised
ribs on battery pack with grooves in the chain saw’s
battery port.
2. Make sure that the latch on bottom of the battery
pack snaps in place and that battery pack is securely
attached in the chain saw before beginning operation.
HOLDING THE CHAIN SAW
See page 13.
Always hold the chain saw with your right hand at the rear
handle and your left hand at the front handle. Grip both
handles with the thumbs and ngers encircling the handles.
Ensure that your left hand is holding the front handle so
that your thumb is underneath.
STARTING THE CHAIN SAW
See page 13.
1. Before starting for operation, install the battery pack in
the product, and make sure that the chain brake is in
run position by pulling chain brake lever /hand guard
towards the front handle.
2. To start the product, pull the trigger release, then press
the throttle trigger.
CHECKING AND OPERATING CHAIN BRAKE
1. Engage the chain brake by rotating your left hand
around the front handle. Allow the back of your hand to
push the chain brake lever/hand guard toward the bar
while the chain is rotating rapidly. Be sure to maintain
both hands on the saw handles at all times.
2. Reset the chain brake back into the Run position by
grasping the top of the chain brake lever / hand guard
and pulling toward the front handle until you hear a
click.
WARNING
If the chain brake does not stop the chain immediately, or
if the chain brake will not stay in the run position without
assistance, take the saw to an authorised service centre
for repair prior to use.
TRANSPORTATION AND STORAGE
See pages 25-28.
■ Stop the product, remove the battery pack, and allow
the product to cool before storing or transporting.
■ Clean all foreign material from the product. Store it in a
cool dry and well-ventilated place that is inaccessible to
children. Keep the product away from corrosive agents
such as garden chemicals and de-icing salts. Do not
store the product outdoors.
■ Fit guide bar cover before storing the product, or during
transportation.
■ For transportation, secure the product against
movement or falling to prevent injury to persons or
damage to the product.
TRANSPORTING LITHIUM BATTERIES
Transport the battery in accordance with local and national
provisions and regulations.
Follow all special requirements on packaging and labelling
when transporting batteries by a third party. Ensure that
no batteries can come in contact with other batteries
or conductive materials while in transport by protecting
exposed connectors with insulating, non-conductive caps
or tape. Do not transport batteries that are cracked or
leaking. Check with the forwarding company for further
advice.
MAINTENANCE
WARNING
Use only original manufacturer’s replacement parts,
accessories and attachments. Failure to do so can
cause possible injury, poor performance and may void
your warranty.
WARNING
Servicing requires extreme care and knowledge
and should be performed only be a qualied service
technician. Have the product serviced by an authorised
service centre only. When servicing, use only original
replacement parts.
