See Figure 35.
See Figures 36 - 45.
n
n
n
1. Press in on the clutch cover lock knob and rotate
counterclockwise until the clutch cover can be
removed.
2. Remove the bar and chain from the mounting surface.
3. Remove the old chain from the bar.
4. Lay out the new saw chain in a loop and straighten any
kinks. The cutters should face in the direction of chain
rotation. If they face backwards, turn the loop over.
5. Place the chain drive links into the bar groove as
shown.
6. Position the chain so there is a loop at the back of
the bar.
7. Hold the chain in position on the bar and place the loop
around the sprocket.
8. Fit the bar ush against the mounting surface so that
the bar studs are in the long slot of the bar.
9. Replace the clutch cover ensuring that the adjusting
pin in the clutch cover is in the bar chain tensioning
pin hole.
10. Replace the clutch cover and rotate clutch cover lock
knob just enough to hold the cover in position.
