Ryobi RM480e Series Assembly Guide

2 — English
 Rules for Safe Assembly .................................................................................................................................................. 2
 Symbols ............................................................................................................................................................................ 3
 Tools Needed .................................................................................................................................................................... 3
Unpacking ........................................................................................................................................................................ 4
 Loose Parts List ................................................................................................................................................................ 5
 Assembly .......................................................................................................................................................................6-7
 Final Preparation ..............................................................................................................................................................8
WARNING:
Strictly adhere to all torque wrench tightening specifica-
tions. Failure to do so could cause serious personal injury.
All information, illustrations, photographs, and specifications
contained in this manual are based on the latest product
information available at the time of publication. Due to im-
provements or other changes, there may be some discrep-
ancies in this manual. We reserve the right to make product
changes at any time, without notice and without incurring
any obligation to make the same or similar changes to any
products previously built or sold.
Any person attempting to assemble this product must
have proper training and experience. Read this manual
carefully and follow all assembly procedures as described.
All assembly must be completed with the unit on a level
surface.
RULES FOR SAFE ASSEMBLY
TABLE OF CONTENTS

Ryobi RM480e Series Specifications

General

Battery Voltage	48V
Battery Capacity	75 Ah
Deck Material	Steel
Number of Blades	2
Drive Type	Rear-Wheel Drive
Transmission	Automatic
Cutting Height Range	1.5 to 4.5 inches
Number of Cutting Heights	12
Maximum Speed	8 mph
Motor	Brushless
Cutting Width	38 inches
Battery Type	Lead Acid
