Ryobi RM480e Series Assembly Guide

9 — English
FINAL PREPARATION
Fig. 7
TEST THE SAFETY INTERLOCK SYSTEM
See Figure 7.
This mower features a Safety Interlock System to protect
the operator by shutting off the blades if the operator leaves
the seat with the blades running. Test the system to be sure
it is working correctly.
To test:

Make sure direction control switch is in neutral (N) position
and blade engage knob is down.
Install start key and turn to ON position.
Raise blade engage knob to activate blades.
Briefly lift off the seat, but do not get off the mower.
The blades should shut off within 5 seconds. If they don’t,
verify you connected the safety interlock cable as described
on page 6. If the cable is connected but the system still
doesn’t function, contact customer service. Do not oper-
ate the mower until the safety interlock system has been
repaired.

Ryobi RM480e Series Specifications

General

Battery Voltage	48V
Battery Capacity	75 Ah
Deck Material	Steel
Number of Blades	2
Drive Type	Rear-Wheel Drive
Transmission	Automatic
Cutting Height Range	1.5 to 4.5 inches
Number of Cutting Heights	12
Maximum Speed	8 mph
Motor	Brushless
Cutting Width	38 inches
Battery Type	Lead Acid
