5
RYOBI 10 in. TABLE SAW – MODEL NUMBER BTS16
The model number will be found on a plate attached to the motor housing. Always mention the model
number in all correspondence regarding your TABLE SAW or when ordering repair parts.
PARTS LIST
* Standard Hardware Item – May Be Purchased Locally
KEY PART
NO. NUMBER DESCRIPTION QTY.
1 0121010919 COMPRESSION SPRING ..........................................................1
2 0134010224 CAM ...........................................................................................1
3 410138743 * SCREW (8-32 x 1 in.) .................................................................1
4 0121010906 LOCKING SCREW (SS41) ..........................................................1
5 0134010316 LOCKING SHIM (SUS310) .........................................................1
6 0121010220 BEVEL LOCKING LEVER ...........................................................1
7 0134011301 RUBBER PAD (NRB70) ..............................................................1
8 412011113 * WASHER (D10 x D21 x 2t) .........................................................1
9 410181001 * SCREW (M4 x 7 mm) .................................................................4
10 0121010219 GEAR RACK ...............................................................................1
11 410499007 * SCREW (M5 x 8 mm HEX HD.) ..................................................2
12 0121010316 FRONT CABINET SUPPORT PLATE ..........................................1
13 0121010315 CAM ...........................................................................................2
14 412042002 * WASHER (D4) .............................................................................2
15 410134005 * SCREW (M4 x 5 mm PAN HD.) ..................................................2
16 412011113 * WASHER (M10 x 21 x 2t) ...........................................................1
17 0121010230 LOCKING RING .........................................................................1
18 411071004 * NUT (M10) ..................................................................................1
19 411071707 * LOCK NUT (1/4-20) ....................................................................1
20 411011707 * NUT (1/4-20 x 5.5t) ....................................................................2
21 0121010206 BEVEL INDICATOR ....................................................................1
22 410271006 * SCREW w/S WASHER (M4 x 12 mm) ........................................1
23 0000120817 * SCREW (8-16 x 19.05 mm PAN HD.) .........................................2
24 0131010210 CORD CLAMP ...........................................................................1
25 0131010209 SWITCH BOX .............................................................................1
26 410031710 * CARRIAGE BOLT (5/16-18 x 1-1/2 in.) ......................................1
27 089110109912 CABINET w/LABELS ..................................................................1
28 0131020211 WING NUT .................................................................................1
29 0131010318 BLADE WRENCH .......................................................................1
30 0134010331 BLADE WRENCH (21 mm OPEN x 10 mm CLOSED)................1
31 0134010238 KNOB RING ...............................................................................1
32 0121010701 POWER CORD ...........................................................................1
33 452080007 SWITCH ASSEMBLY w/KEY ......................................................1
34 410601001 * SCREW (M4 x 20 mm) ...............................................................4
35 0101040203 CORD CLAMP ...........................................................................1
36 410561002 * SCREW (M4 x 16 mm) ...............................................................4
37 0301030202 WIRE CLAMP .............................................................................2
38 0101010908 SPECIAL NUT (3/8-16 x 3.8 mm) ...............................................2
39 416090001 PIN (4.8 x 1/2 in.)........................................................................2
40 089110109013 LOCKING KNOB ........................................................................4
41 411101702 LOCK NUT (5/16 in.) ..................................................................4
42 0101040201 CABINET PAD ............................................................................4
43 410161010 * SCREW (M6 x 25 mm HEX HD.) ................................................4
44 410181001 * SCREW (M4 x 7 mm) .................................................................5
45 089110109907 DATA LABEL...............................................................................1
46 0121015002 VELCRO TAPE ...........................................................................2
47 412011109 * WASHER (5.2 x 24 X 2t) .............................................................2
48 0121010235 POWER CORD BUSHING .........................................................1
49 089110109010 FRONT PANEL BEVEL SCALE LABEL ......................................1
50 089110109900 WARNING LABEL ......................................................................1
51 089110109909 LEG KNOB LABEL .....................................................................4
52 089110109015 DUST BAG .................................................................................1
53 0101140903 * HEX KEY (M5 x 75 mm) .............................................................1
54 0131010243 SWITCH KEY .............................................................................1
