4
English
GB
FR DE ES IT NL PT DK SE FI NO RU PL CZ HU RO LV LT EE HR SI SK GR TR
Blade type Diamond
Blade inner diameter 25,4 mm
Maximum depth of cut 33 mm
Measured values determined
according to EN 61029
A-weighted sound pressure level L
pA
= 61,0 dB(A)
Uncertainty K 3 dB(A)
Measured values determined
according to EN 61029
A-weighted sound power level L
WA
= 77,0 dB(A)
Uncertainty K 3 dB(A)
KNOW YOUR TILE SAW
178 mm tile cutting blade
– A 178 mm tile cutting blade is included with your
saw.
Bevel table
– Beveled 22,5° and 45° cuts can be made using the
bevel table.
Handles
– Saw has convenient handles located on left and
right side for lifting and carrying.
Mitre guide
– The Mitre guide is fully adjustable for diagonal cuts
and Mitre cuts.
Motor
– This machine has a strong motor with sufficient
power to handle tough cutting jobs.
Rip guide
– Rip guide is fully adjustable for making cross cuts
and using the Mitre guide.
Tile saw stand
– This saw comes with a stand for increased
portability and convenience.
Blade guard
– The blade guard provides protection from
overspray and mist
ASSEMBLY
INSTALLING THE BLADE GUARD
See Figure 5–6.
1. Remove bevel table.
2. Install the L-shaped blade guard bracket into the lip
located under the table behind the blade.
3. Install screws into the table and through the blade
guard bracket then tighten securely.
NOTE: Be sure that blade guard bracket is aligned
always be plugged into the wall outlet and not at the
connection of an extension cord and the power tools’
power cord.
If a protected outlet is not available, do not use the saw
until an outlet can be changed or auxiliary protection
can be obtained. These auxiliary protection devices are
available at your local retailer.
POSITION OF THE TILE SAW
See Figure 2.
To avoid the possibility of the tool plug or outlet getting
wet, position tile saw to one side of a wall-mounted outlet
to prevent water from dripping onto the outlet or plug.
The operator should arrange a “drip loop” in the cord
connecting the saw to the outlet. The “drip loop” is that part
of the cord below the level of the outlet, or the connector if
an extension cord is used, to prevent water traveling along
the cord and coming in contact with the outlet.
If the plug or outlet does get wet, DO NOT unplug the cord.
Disconnect the fuse or circuit breaker that supplies power
to the tool then unplug and examine for the presence of
water in the outlet.
WARNING
To reduce the risk of electrocution, keep all connections
dry and off the ground. Do not touch the plug with wet
hands.
SPECIFICATIONS
Product Specifications
Voltage 220 - 240V
Power 500 W
No-load speed 2,900 min
-1
Weight 15,5 kg (N.W.)
Features
Table size 381 mm x 502 mm
Table height from cabinet to table 181 mm
Material Specifications
Table material Stainless steel
Stand material Steel tubing
Cutting Tools/Capacity
Blade diameter 178 mm
