S2Tech DS EUROPE AN-401plus Series User Manual

Preliminary manual AN 401 Plus V2 r12 25/10/12
-16 / 20-
7 Measurement functions
By pressing pushbutton “” Alarm levels configuration menu is entered.
Alarm levels menu
Parameter
Description
Default
Possible values
LEV0
Level 0 switching value
1000
±99999
HIS0
Level 0 hysteresis
0
from 0 to 50
SET0
Level 0 configuration
0
See SET parameter
LEV1
Level 1 switching value
1000
±99999
HIS1
Level 1 hysteresis
0
from 0 to 50
SET1
Level 1 configuration
0
See SET parameter
LEV2
Level 2 switching value
1000
±99999
HIS2
Level 2 hysteresis
0
from 0 to 50
SET2
Level 2 configuration
0
See SET parameter
LEV3
Level 3 switching value
1000
±99999
HIS3
Level 3 hysteresis
0
from 0 to 50
SET3
Level 3 configuration
0
See SET parameter
SET parameter
Working MODE
Function
0
Relay disabled
1
Relay activates on GROSS measurement.
2
Relay activates on NET measurement.
3
Relay activates on Positive peak measurement.
4
Relay activates on Negative peak measurement.
Measures
 NET
 GROSS
 TARE
Display
 NET = (GROSS – Dynamic ZERO)
Keyboard
 Push button C
 Set Dynamic ZERO = Measured value
 Push button E
 When pressed display shows Dynamic ZERO value
 Push button 
 Level setting menu
 Push button 
 When pressed display shows GROSS
Inputs
 Key 1
 Set Dynamic ZERO = Measured value
 Key 2
 Hold of the measurement
 Key 3
 Keyboard lock / protection enforcement
 Key 4
 If active it stores the measured peak value
Relays
 RL0
 Level 0 functions
 RL1
 Level 1 functions
 RL2
 Level 2 functions
 RL3
 Level 3 functions
