Saba LVSL4915X - Water Connection

WARNING!
• Improper connection of the equipment earthing conductor can
result in the risk of an electric shock�
• Check with a qualied electrician or service representative if
you are in doubt whether the appliance is properly earthed�
• Do not modify the plug provided with the appliance� If the
plug does not t properly to the outlet, please have a qualied
electrician to install a proper outlet�
Water Connection
Cold Water Connection
Connect the cold water supply hose to a
threaded 3/4(inch) connector and make sure
that it is fastened tightly in place�
If the water pipes are new or have not been
used for an extended period of time, let the water run to make
sure that the water is clear� This precaution is needed to avoid the
risk of the water inlet to be blocked and damage the appliance�
WARNING! Please close the hydrant after using�
Drain hose Connection
Insert the drain hose into a drain pipe with a minimum diameter
of 4cm, or let it run into the sink, making sure to avoid bending
or crimping it� Use the special plastic support that comes with
the appliance � The top of the hose must be at a height between
40and 100cm�
The free end of the hose must not be immersed in water to avoid
the back ow of it�
How to Drain Excess Water From Hoses
If the sink is 1000 higher from the oor, the excess water in hoses
cannot be drained directly into the sink� It will be necessary to
drain excess water from hoses into a bowl or suitable container
that is held outside and lower than the sink�
Water Outlet
Connect the water drain hose� The drain hose must be correctly
tted to avoid water leaks� Ensure that the water drain hose is not
kinked or squashed�
Close the drain hose
hook to the counter
Front
Drain pipe
Drain hose hook
Counter
NOTE
The top of the hose must be at a height between 40 and 100cm�
The free end of the hose must not be immersed in water�
PLEASE HANG UP THE DRAIN HOSE EITHER WAY OF A, B, C
