English
13
2
2.4Technical Specifications
2
Size (w x h x d)280 x 398 x 460 mm
Weightapprox. 10 kg
Machine housing materialThermoplastic material
Power RatingSee the data plate
Supply VoltageSee the data plate
Power cord lengthapprox. 1,200 mm
Water mains connection3/8" gas (only on models with water mains connection)
Water mains pressureSee the data plate
CapacityWater tankapprox. 2.5 litres
Coffee grounds drawer18 grounds
Control panelFront panel
A-weighted sound pressure levelless than 70 dB
Pump pressureMax. 1.5 MPa (15.0 bar)
Operating conditionsMinimum temperature: above 2°C
Maximum temperature: below 32°C
Maximum humidity: below 80%
Safety devicesBoiler pressure safety valve
Safety thermostat
222222
PRData plate for maximum water supply pressure
2222
Subject to engineering and manufacturing changes due to technological improvements.
