MAIN PARTS
1 Tank lid with lock 10 Drip tray
2 Water tank 11 Accessory drawer
3 Display 12 Coffee grounds drawer
4 Control panel 13 Coffee bean hopper
5 Cappuccinatore compartment cover 14
Service compartment door (to be used by the Service
provider only)
6 Hot water/Steam wand 15 Front cover
7 Coffee dispensing spout 16 Cappuccinatore
8 Cup holder grill 17 ON/OFF button
9 Full drip tray float 18 Chassis plug
The "key to components" includes all machine models;
check which one matches your machine. Certain functions
may not be available.
