13 14
7. Locate Buckle’s Metal
Retainer
Fully recline the child restraint.
Reach under the seat between base
and shell.
8. Rotate Metal Retainer
and Push It Up Through
Shell and Pad
5. Unthread Buckle
Do not unbuckle the buckle.
6. Pull Harness Strap Out of
Seat
9. From Top of Seat,
Pull Buckle Out of Shell
and Pad
For Booster Seat Use
Store the harness strap, chest clip, and
buckle for future use.
Store the splitter plate by wrapping the
harness adjustment strap/splitter plate
around the center rib as shown.
4. Unthread Chest Clip
4358-6870 CAN Alpha Select ENG.indd C13-C144358-6870 CAN Alpha Select ENG.indd C13-C14 2/10/16 12:18 PM2/10/16 12:18 PM
