To Store Lower Anchor Belt
The lower anchor belt MUST be properly
stored in its storage location on the shell
behind the harness straps when:
• using the vehicle belts to install the
car seat; OR
• using the Booster Seat Mode; OR
• the car seat is not installed in the
vehicle.
To Remove Lower Anchor Belt
from Vehicle’s Lower Anchor Bars
1. Remove the tension from the belt
by pushing down on the side of the car
seat with the adjuster.
2. Press the adjuster’s button to loosen
the belt.
3. Squeeze the spring lever on the
hooks, push the hooks back into the
vehicle seat, and rotate the hooks to
the side.
4. Pull the hooks off of the vehicle’s
lower anchor bars.
66
DO NOT use both the lower anchor belt and vehicle
belt at the same time.
WARNING:
Secure the hooks to the attachments in the storage location on the
shell behind the harness straps as shown. Gently tighten the belt to
remove slack.
