Saftronics CV10 User Manual

CV10
Quick Start Guide
SEPTEMBER 2004 10
10V
AIN
COM COM
10V
AIN
Potentiometer
Input
External Signal
Input
External 0-10V or
0- 20 mA Signal
100%
0%
Figure 1
Set SW2 switch per Table 1 based on the type of analog signal connected to the drive (use 0 - 10 VDC
position for potentiometer input).
Type of external signal Remarks
0~10VDC analog signal
0~20mA analog signal
External control is
1-06=0002
V
I
V
I
Table 1
