Saftronics GP10 - Page 27

26
E: Terminal Extensions Functions
Pg.
Func.
Factory Setting Data Change
No.
Setting Range Unit
Min.
30 HP 40 HP Format During op
E01
X1 terminal function
E01
X1 FUNC 0 to 32
0
1N
E02
X2 terminal function
E02
X2 FUNC
1
1N
E03
X3 terminal function
E03
X3 FUNC
2
1N
E04
X4 terminal function
E04
X4 FUNC
3
1N
E05
X5 terminal function
E05
X5 FUNC
-- 4
1N
E06
X6 terminal function
E06
X6 FUNC
5
1N
E07
X7 terminal function
E07
X7 FUNC
6
1N
E08
X8 terminal function
E08
X8 FUNC
7
1N
E09
X9 terminal function
E09
X9 FUNC
8
1N
E10
Acceleration time 2 E10
ACC TIME2 0.01 to 3600 s s
0.01 6.00
20.00 12 Y
E11
Deceleration time 2 E11
DEC TIME2
6.00
20.00 12 Y
E12
Acceleration time 3 E12
ACC TIME3
6.00
20.00 12 Y
E13
Deceleration time 3 E13
DEC TIME3
6.00
20.00 12 Y
E14
Acceleration time 4 E14
ACC TIME4
6.00
20.00 12 Y
E15
Deceleration time 4 E15
DEC TIME4
6.00
20.00 12 Y
E16
Torque limiter 2
(driving)
E16
DRV TRQ 2 20 to 150%, 999 % 1
999
1Y
E17
(braking)
E17
BRK TRQ 2 0%, 20 to 150%, 999 % 1
999
1Y
E20
Y1 terminal function E20
Y1 FUNC 0 to 33
0
1N
E21
Y2 terminal function E21
Y2 FUNC
1
1N
E22
Y3 terminal function E22
Y3 FUNC
-- 2
1N
E23
Y4 terminal function E23
Y4 FUNC
7
1N
E24
Y5A, Y5C terminal function E24
Y5 FUNC
10
1N
5-24
E25
Y5 RY operation mode E25
Y5RY MODE 0,1
-1 0
1N
E30
FAR function (Hysteresis)
E30
FAR HYSTR 0.0 to 10.0 Hz Hz 0.1 2.5 3 Y
E31
FDT function (level)
E31
FDT1 LEVEL
0 to120 Hz
Hz 1 60
1
E32
signal (Hysteresis)
E32
FDT1 HYSTR 0.0 to 30.0 Hz Hz 0.1 1.0 3
E33
OL function (mode select)
E33
OL1 WARNING 0: Thermal calculation
-- 0
1
1: Output current
E34
signal (
L
(level)
E34
OL1 LEVEL 5 to 150% of rated drive current A 0.01 motor rated current 19
E35
(timer)
E35
OL1 TIMER 0.1 to 60.0 s s 0.1 10.0 3
E36
FDT2 function (level)
E36
FDT2 LEVEL 0 to 120 Hz Hz 1 60 1
E37
OL2 function (level)
E37
OL2 LEVEL 5 to 150% of rated drive current A 0.01 motor rated current 19
E40
Display coefficient A
E40
COEF A -999.00 to 999.00
-
0.01 0.01 12
E41
Display coefficient B
E41
COEF B -999.00 to 999.00
-
0.01 0.00 12 Y
E42
LED Display filter
E42
DISPLAY FL 0.0 to 5.0 s
s
0.1 0.5 3 Y
E43
LED Monitor (function)
E43
LED MNTR 0 to 12 - - 0 1 Y
E44
(display in STOP mode)
E44
LED MNTR2 0, 1 - - 0 1 Y
E45
LCD Monitor (function)
E45
LCD MNTR 0, 1
-- 0
1Y
E46
(language)
E46
LANGUAGE 0 to 5
-- 1
1Y
E47
(contrast)
E47
CONTRAST 0(soft) to 10(hard)
-- 5
1Y
C:Frequency Control Functions
C01
Jump (Jump freq. 1)
C01
JUMP Hz 1 0 to 120 Hz
Hz 1 0
1
C02
frequency (Jump freq. 2)
C02
JUMP Hz 2
0
1
C03
(Jump freq. 3)
C03
JUMP Hz 3
0
1
C04
(Hysteresis)
C04
JUMP HYSTR 0 to 30 Hz
Hz 1 3
1
C05
Multistep (Freq. 1)
C05
MULTI Hz-1 0.00 to 120.00 Hz
Hz 0.01 0.00
5
C06
frequency (Freq. 2)
C06
MULTI Hz-2
0.00
5
C07
setting (Freq. 3)
C07
MULTI Hz-3
0.00
5
C08
(Freq. 4)
C08
MULTI Hz-4
0.00
5
C09
(Freq. 5)
C09
MULTI Hz-5
0.00
5
C10
(Freq. 6)
C10
MULTI Hz-6
0.00
5
C11
(Freq. 7)
C11
MULTI Hz-7
0.00
5
C12
(Freq. 8)
C12
MULTI Hz-8
0.00
5
C13
(Freq. 9)
C13
MULTI Hz-9
0.00
5
C14
(Freq. 10)
C14
MULTI Hz-10
0.00
5
C15
(Freq. 11)
C15
MULTI Hz-11
0.00
5
C16
(Freq. 12)
C16
MULTI Hz-12
0.00
5
C17
(Freq. 13)
C17
MULTI Hz-13
0.00
5
C18
(Freq. 14)
C18
MULTI Hz-14
0.00
5
C19
(Freq. 15)
C19
MULTI Hz-15
0.00
5
Y
Y
Y
Name
LCD Display
Y
Y
5-26
5-27
5-28
5-18/21
5-22
5-22/24
5-25
