Saftronics GP10 - Outline Dimensions-Variable Torque, Constant Torque

11-7
Outline Dimensions-Variable Torque, Constant Torque
2 to 5 Hp
7.5, 15 Hp-VT
7.5, 10 Hp-CT
20 to 30 Hp-VT
15 to 30 Hp-CT
Type D D1 D2 D3 D4
1/4, 1/2 Hp 5.12 1.44 3.15 3.7 2.81
(130) (26.5) (80) (94) (71.5)
1 Hp 5.71 2.03 3.74 4.29 3.41
(145) (51.5) (95) (109) (86.5)
43
