28
A: Alternative Motor Parameters
Pg.
Func.
Factory Setting Data Change
No.
Setting Range Unit
Min.
30 HP 40 HP
Format During op
A01
Maximum frequency 2
A01
MAX Hz-2 50 to 120 Hz
Hz 1
60 1 N
A02
Base frequency 2
A02
BASE Hz-2 25 to 120 Hz
Hz 1 60
1N
A03
Rated voltage 2
A03
RATED V-2 0
V 1 230V class: 230
1
(at Base frequency 2 ) 230V class:
80 to 240V 460V class: 460
460V class:
320 to 480V
A04
Maximum voltage 2
A04
MAX V-2
230V class:
80 to 240V V 1 230V class: 230
1N
460V class:
320 to 480V 460V class: 460
A05
Torque boost 2
A05
TRQ BOOST2 0.0, 0.1 to 20.0
- - 2.0
3Y
A06
Electronic (select)
A06
ELCTRN OL2
0, 1, 2
-- 1
1Y
A07 thermal 2
(level)
A07
OL LEVEL2
20% to 135% if INV rated current
A 0.01 motor rated current
19 Y
A08
(thermal time constant)
A08
TIME CNST2
0.5 to 75.0 min min 0.1 5.0 10.0 3 Y
A09
Torque vector control 2
A09
TRQVECTOR2
0, 1
-- 0
1N
A10
Number of motor 2 poles
A10
M2 POLES 2 to 14 poles
pole 2 4
9N
A11
Motor 2 (capacity)
A11
M2-CAP Up to 30 HP: 0.01 to 60 HP
HP 0.01
motor capacity 5
40 HP and above: 0.01 to 600 HP
A12
(rated current)
A12
M2-Ir 0.00 to 2000 A
A 0.01 motor rated current
19 N
A13
(tuning)
A13
M2 TUN1 0, 1, 2
-- 0
21 N
A14
(on-line tuning)
A14
M2 TUN2 0, 1
-- 0
1N
A15
(no-load current)
A15
M2-Io 0.00 to 2000 A
A 0.01 standard rated value
19 N
A16
(%R1 setting)
A16
M2-%R1 0.00 to 50.00%
% 0.01 standard rated value
5Y
A17
(%X setting)
A17
M2-%X 0.00 to 50.00%
% 0.01 standard rated value
5Y
A18
(slip compensation control 2)
A18
SLIP COMP2
0.00 to 15.00 Hz Hz 0.01 0.00 5 Y
N
N
5-45
Name
LCD Display
5-44
