40
Three-phase 460V series-Constant Torque
F50 001 002 003 005/007 010 015 020 025 030 040 050 060 075 100 125 150 200 250 300 350 400/450 500 600 700 800
Norminal 460V system applied motor HP 1/2 12357.510152025
Rated Capacity *1) kVA 1.1 1.9 2.9 4.3 7.1 10 14 19 23 31 35 47 59 72 89 119 140 167 201 242 300 330 414
466 518 590
Rated Voltage *2) V 3-phase, 380V , 400V , 415V /50Hz , 380V , 400V , 440V , 460V /60Hz
Rated Current *3) A 1.5 2.5 3.7 5.5 9.0 13 18 24 30 39 45 60 75 91 112 150 176 210 253 304 377 415 520 585 650 740
Overload Capability 110% of rated current for 1min , 150% of rated current for 1min ,
200% of rated current for 0.5s 180% of rated current for 0.5s
Rated Frequency Hz 50, 60Hz
Input Phases, Voltage, Frequency 3-phase, 380 to 480V , 50/60Hz 3-phase, 380 to 440V /50Hz , 380 to 480V /60Hz
ratings * 380V/50Hz and 380 to 415V/60Hz *4)
Voltage / frequency variations -Voltage : +10 to -15% ( Voltage unbalance *5) : 2% or less ) -Frequency :+5 to -5%
Momentary voltage dip When the input voltage is 310V or more, the inverter can be operated continuously.
capability *6) When the input voltage drops below 310V from rated voltage, the inverter can be operated for 15ms . (less than 85% load of nominal applied motors)
The smooth recovery method is selectable.
Output
Maximum Freq. 50 to 120Hz *10)
frequency
Base Freq. 25 to 120Hz *10)
Setting Starting Freq. 0.1 to 60Hz , Continuous time : 0.0 to 10.0s
Carrier Freq. *8) 0.75 to 15kHz 0.75 to 6kHz
The minimum carrier frequency changes depend on maximum output frequency.
0.75 - 10kHz
Accuracy (Stability) -Analog setting : ±0.2% of Maximum frequency (at 25 ±10 degrees C)
-Digital setting : ±0.01% of Maximum frequency (at -10 to +50 degrees C)
Setting resolution -Analog setting : 1/3000 of Max. frequency ex.) 0.02Hz at 60Hz , 0.15Hz at 400Hz
-Digital setting : 0.01Hz at Maximum frequency of up to 99.99Hz (0.1Hz at Maximum frequency of 100Hz and above)
-Link setting
: Two methods are selectable.
Control Volt/Freq Characteristic 320 to 480V (with AVR control) at base and maximum frequency, adjustable
Torque boost Constant torque load Variable torque load
Automatic (setting code) 0.0 -
Manual (setting code) 2.0 to 20.0 0.1 to 1.9 *9)
Starting torque 200% (with Dynamic torque vector control selected) 180% (with Dynamic torque vector control selected)
Braking
Braking torque 150% 100% 20% *11) 15 to 10% *11)
Standards Time
Duty cycle %
Braking torque 150% 100%
Options Time s 45 45 30 20 10 8 1 0
Duty cycle % 22 7 5 5 5 10
DC injection braking Starting frequency : 0.1 to 60.0Hz , Braking time : 0.0 to 30.0s, Braking level : 0 to 100% of rated current
Enclosure NEMA Type1, Type 4 NEMA Type1, Type12 Open, Open with NEMA Type 12 Heatsink, NEMA Type 1
Cooling method Natural Fan cooling
Standards -UL/cUL
NOTES
*1) Inverter output capacity [kVA] at 460V.
*2) Output voltage is proportional to the power supply voltage and can't exceed the power supply voltage.
*3) Current derating may be required in case of low impedance load such as high frequency motor.
*4) Change the tap of auxiliary transformer.
380V/50Hz and 380 to 415V/60Hz : Change over CN UX connector from U1 part to U2 part. (Reference to the Instruction manual)
Input voltage
CN UX connector
400 to 440V/50Hz, 440 to 480V/60Hz
U1 (Factory setting)
380V/50Hz (398V or smaller),
380 to 415V/60Hz (430V or smaller)
*5) Reference to the IEC 61800-3( 5.2.3 )
(Maximum voltage[V] - Minimum voltage[V] )
3-phase averaging voltageV
*6) Input power : 85%
*8) If carrier frequency is set at more than 10kHz and an overheat condition (detected by internal thermal sensor ) occurs, inverter will automatically reduce carrier frequency to 8kHz ,
in order to avoid trip.(Available up to 30HP unit)
*9) When setting into 0.1, the starting torque gets 50%
*10) Above 120Hz application, please contact the factory
*11) With a nominal applied motor.(Average torque when the motor decelerates and stops from 60Hz. It may change according to the motor loss.)
-LOW VOLTAGE directive -IEC 61800-2 Rating,
specifications for low voltage adjustable frequency a.c
power drive systems)
-EMC directive -IEC 61800-3 (EMC product
standard including specific test methods)
1/ 2000 0 of Ma x i mum f r equenc y e x . ) 0 . 00 3Hz a t 60Hz , 0. 01Hz at 400Hz
0. 01Hz ( F i x ed)
Unbal a nc e i n power s uppl y v ol t a ge [ %] =
X
1 00 [ %]
U2
Type designation
( * * indicate product revision)
GP10E1ST34_ _ _* * (NEMA Type1)
GP10E2ST34_ _ _* * (NEMA Type12)
GP10E4ST34_ _ _* * (NEMA Type 4)
GP10E8ST34_ _ _* * (Open, Type 12 Heatsink)
GP10E9ST34_ _ _* * (Open)
30
40 50
60
75
100
125
150
200
250
300 350
400
450
500 600
s
5
5
No limit
5 3 5 3 2 3 2 No limit
10
