46
Outline Dimensions Open Type-Variable Torque/ Constant Torque
Surface Mount Through Panel Mount
230V Series-Variable Torque, Constant Torque
Hp Mtg. Weight
230V W W1 W2 W3 H H1 H2 H3 H4 H5 H6 D D1 D2 C Bolts Lb (kg)
40/30 13.4 9.4 12.8 21.7 20.9 19.7 20.2 0.5 1 0.4 10 5.7 0.2 0.4 M8 64
(340) (240) (326) (550) (530) (500) (512) (12) (25) (9) (255) (145) (4) (10) (29)
50/40
14.8 10.8 14.2 24.2 23.4 22.2 22.7 10.6 79
(375) (275) (361) (615) (595) (565) (577) (270) (36)
60/50
29.1 28.3 27.2 27.6 97
(740) (720) (690) (702) (44)
75/65
101
(46)
100/75
20.9 16.9 20.1 29.5 27 27.4 0.6 1.3 0.5 11.2 0.6 M12 154
(530) (430) (510) (750) (685) (695) (16) (33) (13) (285) (15) (70)
125/100
26.8 22.8 26 34.6 33.5 32.1 32.5 14.2 8.7 253
150/125 (680) (580) (660) (880) (850) (815) (825) (360) (220) (115)
460V Series-Variable Torque, Constant Torque
Hp Mtg. Weight
460V W W1 W2 W3 H H1 H2 H3 H4 H5 H6 D D1 D2 C Bolts Lb (kg)
40/30 13.4 9.4 12.8 21.7 20.9 19.7 20.2 0.5 1 0.4 10 5.7 0.2 0.4 M8 64
(340) (240) (326) (550) (530) (500) (512) (12) (25) (9) (255) (145) (4) (10) (29)
50/40
14.8 10.8 14.2 10.6 75
(375) (275) (361) (270) (34)
60/50
26.6 25.8 24.6 25.1 86
(675) (655) (625) (637) (39)
75/65
88
(40)
100/75
29.1 28.3 27.2 27.6 106
(740) (720) (690) (702) (48)
125/100
20.9 16.9 20.1 28 26.6 27 0.6 1.3 0.5 12.4 6.9 0.6 M12 154
150/125
(530) (430) (510) (710) (675) (682) (16) (33) (13) (315) (175) (15) (70)
200/150
39.4 38.2 36.8 37.2 14.2 8.7 220
250/200
(1000) (970) (935) (945) (360) (220) (100)
300/250
26.8 22.8 26 11.4 308
(680) (580) (660) (290) (140)
350/300
400/350
450/350
DIMENSION Inch (mm)
DIMENSION Inch (mm)
H1
