Sagem MA 500+ Series User Manual

SSE-0000053018-04 Sagem Sécurité document. Reproduction and disclosure forbidden.
27
E
E
t
t
h
h
e
e
r
r
n
n
e
e
t
t
w
w
i
i
r
r
i
i
n
n
g
g
2 ways for Ethernet wiring:
- Terminal block connection (MA 500 / MA 500+ Series) only
MA 500 / MA 500+ Series OMA 500 Series
Ethernet cable
1 Block 1
RX- In Receive negative Ethernet RJ45 Pin 6
2 Block 2
RX+ In Receive positive Ethernet RJ45 Pin 3
3 Block 3
TX- Out Transmit negative Ethernet RJ45 Pin 2
4 Block 4
TX+ Out Transmit positive Ethernet RJ45 Pin 1
5 Block 5
GND Ground for shield Ethernet RJ45 Pin 7
- RJ 45 cabling connection
RJ45
Pinout
Signals
EIA/TIA
T568B color
EIA/TIA
T568A color
Corel L120
color
1 TX(+) Transmit Data Plus White Orange
White Green Grey
2 TX(-) Transmit Data Minus Orange Green White
3 RX(+) Receive Data Plus White Green White Orange
Pink
4 No connection Blue Blue Orange
5 No connection White blue White blue Yellow
6 RX(-) Receive Data Minus Green Orange Blue
7 Ground protection (option) White Brown White Brown Purple
8 No connection Brown Brown Brown
RJ45 plug pinout is compliant with 10/100 base T, IEEE802.3 Specification.
