Sagem MA 500+ Series User Manual

28
Sagem Sécurité document. Reproduction and disclosure forbidden. SSE-0000053018-04
RJ45 plug and Ethernet terminal block connections are compliant with Power
Over Ethernet (POE) IEEE802.3 af Specification. See details on page 27.
Default IP address from factory setting is: 134.1.32.214
O
O
u
u
t
t
p
p
u
u
t
t
r
r
e
e
l
l
a
a
y
y
a
a
n
n
d
d
s
s
e
e
c
c
u
u
r
r
i
i
t
t
y
y
s
s
w
w
i
i
t
t
c
c
h
h
e
e
s
s
MA 500 / MA 500+ Series OMA 500 Series
Switch/relay cable
1 Block 1
CRO Contact relay normally open Red
2 Block 2
CRC Contact relay normally closed Orange
3 Block 3
CR Contact relay common Yellow
4 Block 6
TSW2_1 Tamper switch Contact 1 White
5 Block 7
TSW2-0 Tamper switch Contact 0 Green
6 Block 4
ATSW1_1 Anti theft switch Contact 1 Not available
7 Block 5
ATSW1_0 Anti theft switch Contact 0 Not available
Ground Not connected Black (*)
(*): For this interface connection, it is not recommend to connect black wire to
Ground. Various ground reference are not recommended.
This terminal is part of security system. In order to prevent unauthorized
access into this terminal it is the customer’s responsibility to connect the
tamper switch and the anti theft switch (MA 500 / MA 500+ Series only) to the
physical access controller (connected mode).
