11
C9 0 120 s 10 compressor 2 delay from power up of compressor 1 (only if u1 = 3)
C10 0 9999 h 0
number of hours of compressor operation above which maintenance request is
indicated 0 = no function
LABEL MIN. MAS. U.M. DEF. DEFROST
d0 0 99 h 6
defrost interval; also look at d8 (9)
0=the defrost at intervals will never be activated
d1 0 1 - 0 kind of defrost (0=electric defrost 1=hot gas defrost)
d2 -99 99 °C/°F (1) 8 defrost cutoff temperature (only if P3 = 1)
d3 0 99 min 30
defrost duration if P3 = 0 or 2; defrost maximum duration if P3 = 1
0=the defrost will never be activated
d4 0 1 - 0 defrost when you turn on the instrument (1 = YES) (4)
d5 0 99 min 0 defrost delay when you turn on the instrument (only if d4 = 1); see also i5 (4)
d6 0 1 - 1
temperature shown during the defrost (only if P5 = 0)
0=cabinet temperature
1=if to the defrost activation the cabinet temperature is below “working setpoint
+ r0”, at most “work-ing setpoint + r0”; if to the defrost activation the cabinet
temperature is above “working setpoint +r0”, at most the cabinet temperature
to the defrost activation (10)
d7 0 15 min 3 dripping duration
d8 0 2 - 0
kind of defrost interval
0=the defrost will be activated when the instrument will have remained turned
on the time d0
1=the defrost will be activated when the compressor will have remained turned
on the time d0
2=the defrost will be activated when the evaporator temperature will have
remained below the tem-perature d9 the time d0 (11)
d9 -99 99 °C/°F (1) 0
evaporator temperature above which the count of the defrost interval is
suspended (only if d8 = 2)
dA 0 99 min 0
minimum time the compressor must be remained turned on (to the defrost
activation) in order that thedefrost can be activated (only if d1 = 1) (12)
LABEL MIN. MAS. U.M. DEF. TEMPERATURE ALARMS
A0 0 2 - 0
temperature joined to the lower temperature alarm
0=cabinet temperature
1=evaporator temperature (13)
2 = temperature detected by the auxiliary probe (only if P4 = 1 or 2) (14)
A1 -99 99 °C/°F (1) -2
temperature below which the lower temperature alarm is activated; also look at
A0 and A2 (7)
A2 0 2 - 1
kind of lower temperature alarm
0=alarm not enabled
1=relative to the working setpoint (or "working setpoint - A1”; consider A1
without sign)
2=absolute (or A1)
A3 0 1 - 0
temperature associated with the maximum temperature alarm
0 = cabinet temperature
1 = temperature detected by the auxiliary probe (only if P4 = 1 or 2) (14)
A4 -99 99 °C/°F (1) 15
temperature above which the upper temperature alarm is activated; also look
at A3 and A5 (7)
A5 0 2 - 1
kind of upper temperature alarm
0=alarm not enabled
1=relative to the working setpoint (or "working setpoint + A4”; consider A4
without sign)
2=absolute (or A4)
A6 0 240 min 120
upper temperature alarm delay since you turn on the instrument (only if A3 = 0
or if P4 = 1 and A3 = 1) (4))
A7 0 240 min 15 temperature alarm delay
A8 0 240 min 60
upper temperature alarm delay since the end of the after dripping evaporator
fan delay (only if A3 = 0)( 15)
A9 0 240 min 15
maximum temperature alarm delay on microport input deactivation (only if A3 =
0 or if P4 = 1 and A3 = 1) (16)
LABEL MIN. MAS. U.M. DEF. EVAPORATOR FAN
F0 0 4 - 1
evaporator fan activity during the normal operation
0=turned off
1=turned on
2=according to the compressor
3=according to F1 (17)
4=turned off if the compressor is turned off, according to F1 if the compressor
is turned on (17)
F1 -99 99 °C/°F (1) -1
evaporator temperature above which the evaporator fan is turned off
(only if F0 = 3 or 4) (7)
F2 0 2 - 0
evaporator fan activity during the defrost and the dripping
0=turned off
1=turned on
2=according to F0
