Sailor AP5065 - Page 17

15
Alarm panel with mounting bracket
40723B
140
120
Panel mounting kit (Option)
Part no 405065A-920
9.6
Space for cable entry
min. 150
Drilling plan
105
105
6
108
128 6
4 x ø5
17.5
7.5
4 x ø3.5 uns for M3 ISO 14581
20 20
4 pcs M4x30
4 pcs M3x30
3 pcs M3x8
Cut out
Drilling plan
0736
