6 PARTSLIST RT2047 DSC - PART II
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
PAGE 5-2
9810
C130 CAPACITOR CERAMIC 33pF 5% N150 50VDC KCK RT-HE50 SK PH 330 J 15.092
C131 CAPACITOR POLYSTERENE 120pF 1% 630V #PHILIPS 2222 431 81201 10.403
C132 CAPACITOR MKT 100nF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C133 CAPACITOR MKT 100nF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C134 CAPACITOR POLYSTYRENE 180pF 1% 630VDC PHILIPS 2222 431 81801 10.407
C135 CAPACITOR MKT 100nF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C136 CAPACITOR MKT 330nF 5% 63VDC PHILIPS 2222 370 79334 11.184
C137 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ERO EKI 00 AA 210 F M5K 14.512
C138 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ERO EKI 00 AA 210 F M5K 14.512
C139 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ERO EKI 00 AA 210 F M5K 14.512
C140 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ERO EKI 00 AA 210 F M5K 14.512
C141 CAPACITOR MKT 100nF 10% 63VDC PHILIPS 2222 370 75104 (78104) 11.136
C142 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ERO EKI 00 AA 210 F M5K 14.512
C143 CAPACITOR CERAMIC 1nF 10% 50VDC CL2 KCK RT-SK-HE50 SJYB 102 K 16.160
C144 CAPACITOR CERAMIC 1nF 10% 50VDC CL2 KCK RT-SK-HE50 SJYB 102 K 16.160
C145 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
D101 DIODE CAPASITANCE 13pF/9VDC TOSHIBA 1SV101 in matched group 26.135
D102 DIODE CAPASITANCE 13pF/9VDC TOSHIBA 1SV101 in matched group 26.135
D103 DIODE CAPASITANCE 13pF/9VDC TOSHIBA 1SV101 in matched group 26.135
D104 DIODE CAPASITANCE 13pF/9VDC TOSHIBA 1SV101 in matched group 26.135
FL101 CRYSTAL FILTER 21.4 MHz NDK 21F15DH 40.022
FL102 STETT, CFU 455 D2 81004552
U101 NBFM IF SYSTEM MC3361 PHILIPS MC 3361 N 31.325
U102 POS. VOLTAGE REG. FIXED 5V/0.1A 78L05AC MOTOROLA MC78L05ACP RA 31.135
L101 COIL TL355 ECI A/S 6-0-23627 400355
L102 COIL TL356 ECI A/S 6-0-23628 400356
L103 COIL TL357 ECI A/S 6-0-23629 400357
L104 COIL TL358 ECI A/S 6-0-23630 400358
L105 COIL TL360 ECI A/S 6-0-23632A 400360
L106 COIL TL361 ECI A/S 6-0-23633 400361
L107 CHOKE FIXED 4u7H 10% SIEMENS B78108-T1472-K 20.355
L108 COIL RF 568nH ADJUSTABLE SUMIDA ELEC.CO. P-75B / 2175-2239-1025 38.432
L111 COIL TL359 ECI A/S 6-0-23631 400359
R101 RESISTOR MF 33k OHM 5% 0.4W PHILIPS 2322 181 53333 01.237
R102 RESISTOR MF 33k OHM 5% 0.4W PHILIPS 2322 181 53333 01.237
R103 RESISTOR MF 180 OHM 5% 0.4W PHILIPS 2322 181 53181 01.181
R104 RESISTOR MF 1k5 OHM 5% 0.4W PHILIPS 2322 181 53152 01.204
R105 RESISTOR MF 4k7 OHM 5% 0.4W PHILIPS 2322 181 53472 01.216
R106 RESISTOR MF 33k OHM 5% 0.4W PHILIPS 2322 181 53333 01.237
R107 RESISTOR MF 33k OHM 5% 0.4W PHILIPS 2322 181 53333 01.237
R108 RESISTOR MF 330 OHM 5% 0.4W PHILIPS 2322 181 53331 01.187
R109 RESISTOR MF 1k2 OHM 5% 0.4W PHILIPS 2322 181 53122 01.202
R110 RESISTOR MF 3k9 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-3k9 01.714
R111 RESISTOR MF 82 OHM 5% 0.4W PHILIPS 2322 181 53829 01.172
R112 RESISTOR MF 2k2 OHM 5% 0.4W PHILIPS 2322 181 53222 01.208
R113 RESISTOR MF 12k OHM 5% 0.4W PHILIPS 2322 181 53123 01.227
R114 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R115 RESISTOR MF 10 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-10R 01.650
R116 RESISTOR MF 150 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-150R 01.679
R117 RESISTOR MF 150 OHM 5% 0.4W PHILIPS 2322 181 53151 01.179
R118 RESISTOR MF 5k36 OHM 1% 0.6W PHILIPS 2322 156 15362 03.418
R119 RESISTOR MF 1k5 OHM 5% 0.4W PHILIPS 2322 181 53152 01.204
R120 RESISTOR MF 43k OHM 5% 0.4W PHILIPS 2322 181 53433 01.240
R121 RESISTOR MF 3k9 OHM 5% 0.4W PHILIPS 2322 181 53392 01.214
R122 RESISTOR MF 47k OHM 5% 0.4W PHILIPS 2322 181 53473 01.241
R123 RESISTOR MF 27k OHM 5% 0.4W PHILIPS 2322 181 53273 01.235
R124 RESISTOR MF 27k OHM 5% 0.4W PHILIPS 2322 181 53273 01.235
R125 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R126 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R127 RESISTOR MF 220 OHM 5% 0.4W PHILIPS 2322 181 53221 01.183
R128 RESISTOR MF 470 OHM 5% 0.4W PHILIPS 2322 181 53471 01.191
R129 RESISTOR MF 220 OHM 5% 0.4W PHILIPS 2322 181 53221 01.183
Q101 TRANSISTOR RF LOW POWER PNP BF979/BF479 TELEFUNKEN AG BF979 28.250
Q102 TRANSISTOR N-CHAN. JFET TIS88A2 MOTOROLA TM00 044-2 29.736
Q103 TRANSISTOR MOSFET BF961 TFK* BF961 29.755
Q104 TRANSISTOR AF BC547B NPN TO-92 MOT. BC547BZL1 28.067
X101 20,9450MHZ 20PPM HC43/U 38350131
