6 PARTSLIST RT2047 DSC - PART II
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
PAGE 5-3
9810
RX-SYNTHESISER MODULE 200 ECI A/S 5-0-23694D 600012
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
C201 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C202 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C203 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C204 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C205 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C206 CAPACITOR CERAMIC 27pF 5% N150 50VDC KCK RT-HE50 SK PH 270 J 15.812
C207 CAPACITOR CERAMIC 10pF 5% NPO 500VDC KCK RT-HM60 SK CH 100 J 15.565
C208 CAPACITOR CERAMIC 27pF 5% N150 50VDC KCK RT-HE50 SK PH 270 J 15.812
C209 CAPACITOR CERAMIC 27pF 5% N150 50VDC KCK RT-HE50 SK PH 270 J 15.812
C210 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C211 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ERO EKI 00 AA 233 D M5K 14.518
C212 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C213 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C214 CAPACITOR CERAMIC 16pF 5% N150 50VDC KCK RT-HE40-SK PH 160 J 15.057
C215 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C216 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C217 CAPACITOR CERAMIC 15pF 5% NPO 500VDC KCK RT-HM60 SK CH 150 J 15.590
C218 CAPACITOR POLYESTER 150nF 10% 100VDC PHILIPS 2222 372 28154 11.074
C219 CAPACITOR POLYESTER 68nF 10% 250V ERO MKT1822 11.102
C220 CAPACITOR POLYSTYRENE 820pF 1% 250VDC PHILIPS 2222 430 88201 10.348
C221 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C222 CAPACITOR CERAMIC 22pF 5% N150 500VDC KCK RT-HM SK PH 220 J 15.062
C223 CAPACITOR POLYESTER 68nF 10% 250V ERO MKT1822 11.102
C224 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C225 CAPACITOR MKT 2u2F 10% 100VDC ERO MKT 1822-522/01 5 R 11.142
C226 CAPACITOR CERAMIC 100pF 5% N150 500V #KCK HM11SJPH101J 15.132
C227 CAPACITOR CERAMIC 1nF 10% 50VDC CL2 KCK RT-SK-HE50 SJYB 102 K 16.160
C228 CAPACITOR CERAMIC 1nF 10% 50VDC CL2 KCK RT-SK-HE50 SJYB 102 K 16.160
C229 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ERO EKI 00 AA 233 D M5K 14.518
C230 CAPACITOR MKT 100nF 10% 100VDC ERO MKT 1822-410/01 5 11.073
C231 CAPACITOR CERAMIC 1nF 10% 50VDC CL2 KCK RT-SK-HE50 SJYB 102 K 16.160
C232 CAPACITOR CERAMIC 100nF 10% 50V SIEMENS B37987-F5104-K000 16.305
C233 CAPACITOR POLYESTER 0.22uF 10% 100V PHILIPS* 2222 369 28224 11.075
C234 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ERO EKI 00 AA 233 D M5K 14.518
C235 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ERO EKI 00 AA 233 D M5K 14.518
C236 CAPACITOR CERAMIC 33pF 5% N150 400V #KCK HM74SJPH330J 15.083
C237 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C238 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C239 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C240 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C241 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C242 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C243 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C244 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C245 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ERO EKI 00 AA 233 D M5K 14.518
C246 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C247 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
D201 DIODE CAPASITANCE 13pF/9VDC TOSHIBA 1SV101 in matched group 26.135
D202 DIODE BAW62 HIGH SPEED PHILIPS BAW62-143 25.350
D203 DIODE BAW62 HIGH SPEED PHILIPS BAW62-143 25.350
D204 DIODE BAW62 HIGH SPEED PHILIPS BAW62-143 25.350
IC201 INTEGRATED CIRCUIT MC12015P MOTOROLA MC12015P 32.850
IC202 INTEGRATED CIRCUIT 4BIT SER.INP.PLL SYNTHES MOTOROLA SC145146P 33.490
L205 CHOKE 4u7H 10% SIEMENS B78108-T1472-K 20.137
R201 RESISTOR MF 1k5 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-1k5 01.704
R202 RESISTOR MF 1k0 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-1k0 01.700
R203 RESISTOR MF 68 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-68R 01.670
R204 RESISTOR MF 33 OHM 5% 0.4W PHILIPS 2322 181 53339 01.162
R205 RESISTOR MF 68 OHM 5% 0.4W PHILIPS 2322 181 53689 01.170
R206 RESISTOR MF 390 OHM 5% 0.4W PHILIPS 2322 181 53391 01.189
R207 RESISTOR MF 560 OHM 5% 0.4W PHILIPS 2322 181 53561 01.193
R208 RESISTOR MF 560 OHM 5% 0.4W PHILIPS 2322 181 53561 01.193
R209 POTENTIOMETER TRIMMING 470 OHM 10% 0.5W PHILIPS* 2322 484 75471 07.651
R210 RESISTOR MF 56k OHM 5% 0.4W PHILIPS 2322 181 53563 01.243
R211 RESISTOR MF 33 OHM 5% 0.4W PHILIPS 2322 181 53339 01.162
R212 RESISTOR MF 5k6 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-5k6 01.718
R213 RESISTOR MF 1k0 OHM 5% 0.4W PHILIPS 2322 181 53102 01.200
R214 RESISTOR MF 68 OHM 5% 0.4W PHILIPS 2322 181 53689 01.170
