6 PARTSLIST RT2047 DSC - PART II
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
PAGE 5-4
9810
R215 RESISTOR MF 330 OHM 5% 0.4W PHILIPS 2322 181 53331 01.187
R216 RESISTOR MF 1k5 OHM 5% 0.4W PHILIPS 2322 181 53152 01.204
R217 RESISTOR MF 1k0 OHM 5% 0.4W PHILIPS 2322 181 53102 01.200
R218 RESISTOR MF 27 OHM 5% 0.4W PHILIPS 2322 181 53279 01.160
R219 RESISTOR MF 180 OHM 5% 0.4W PHILIPS 2322 181 53181 01.181
R220 RESISTOR MF 4k7 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-4k7 01.716
R221 RESISTOR MF 4k7 OHM 5% 0.4W PHILIPS 2322 181 53472 01.216
R222 RESISTOR MF 6k8 OHM 5% 0.4W PHILIPS 2322 181 53682 01.220
R223 RESISTOR MF 10k OHM 5% 0.4W PHILIPS 2322 181 53103 01.225
R224 RESISTOR MF 390k OHM 5% 0.4W PHILIPS 2322 181 53394 01.264
R225 RESISTOR MF 100 OHM 5% 0.4W PHILIPS 2322 181 53101 01.175
R226 RESISTOR MF 820 OHM 5% 0.4W PHILIPS 2322 181 53821 01.197
R227 RESISTOR MF 390 OHM 5% 0.4W PHILIPS 2322 181 53391 01.189
R228 RESISTOR MF 120 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-120R 01.677
R229 RESISTOR MF 1k0 OHM 5% 0.4W PHILIPS 2322 181 53102 01.200
R230 RESISTOR MF 3k3 OHM 5% 0.4W PHILIPS 2322 181 53332 01.212
R231 RESISTOR MF 12k OHM 5% 0.4W PHILIPS 2322 181 53123 01.227
R232 RESISTOR MF 3k3 OHM 5% 0.4W PHILIPS 2322 181 53332 01.212
R233 RESISTOR MF 2k2 OHM 5% 0.4W PHILIPS 2322 181 53222 01.208
R234 RESISTOR MF 120 OHM 5% 0.4W PHILIPS 2322 181 53121 01.177
T201 TRANSISTOR RF BFW92A TFK BFW92A 29.160
T202 TRANSISTOR JFET TIS88A3 TO-92 MOTORPLA TM 00 044-3 29.737
T203 TRANSISTOR AF BC548B NPN TO-92 PHILIPS BC548B-126 28.076
T204 TRANSISTOR RF BFW92A TFK BFW92A 29.160
T205 TRANSISTOR AF BC558B ITT/MOT BC558B 28.100
T206 TRANSISTOR AF BC548B NPN TO-92 PHILIPS BC548B-126 28.076
T207 TRANSISTOR BC549B PHILIPS* BC549B-126 28.080
T208 TRANSISTOR BC549B PHILIPS* BC549B-126 28.080
T209 TRANSISTOR AF BC548B NPN TO-92 PHILIPS BC548B-126 28.076
T210 TRANSISTOR AF BC558B ITT/MOT BC558B 28.100
L201 COIL TL370 S.P.RADIO 6-0-23686 400370
L202 COIL TL368 ECI A/S 6-0-23592 400368
L203 COIL TL375 ECI A/S 6-0-23696B 400375
L204 COIL TL376 S.P.RADIO 6-0-23697C 400376
L206 COIL TL369 S.P.RADIO 6-0-23662 400369
L207 COIL TL371 ECI A/S 6-0-23687 400371
TX-EXCITER MODULE 300 ECI A/S 5-0-23695D 600100
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
C301 CAPACITOR CERAMIC 4n7F 20% CL2 50VDC KCK RT-HE80-SK YD 472 M 15.165
C302 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C303 CAPACITOR CERAMIC 39pF 5% N150 500V #KCK HM74SJPH390J 15.095
C304 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C305 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C306 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C307 CAPACITOR CERAMIC 33pF 5% N150 400V #KCK HM74SJPH330J 15.083
C308 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C309 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C310 CAPACITOR CERAMIC 18pF 5% NPO 500VDC KCK RT-HM60 SK CH 180 J 15.060
C311 CAPACITOR CERAMIC 15pF 5% NPO 500VDC KCK RT-HM60 SK CH 150 J 15.590
C312 CAPACITOR MKT 10nF 10% 400V SIEMENS B32510-D6103-K000 11.381
C313 CAPACITOR MKT 10nF 10% 400V SIEMENS B32510-D6103-K000 11.381
C314 CAPACITOR MKT 10nF 10% 400V SIEMENS B32510-D6103-K000 11.381
C315 CAPACITOR MKT 220nF 10% 100V SIEMENS B32510-D1224-K000 11.225
C316 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C317 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C318 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C319 CAPACITOR MKT 220nF 10% 100V SIEMENS B32510-D1224-K000 11.225
C320 CAPACITOR CERAMIC 1nF 10% 50VDC CL2 KCK RT-SK-HE50 SJYB 102 K 16.160
C321 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ERO EKI 00 AA 233 D M5K 14.518
C322 CAPACITOR MKT 10nF 10% 400V SIEMENS B32510-D6103-K000 11.381
C323 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C324 CAPACITOR MKT 10nF 10% 400V SIEMENS B32510-D6103-K000 11.381
C325 CAPACITOR POLYSTYRENE 82pF 1% 630V #PHILIPS 2222 431 88209 10.398
C326 CAPACITOR CERAMIC 180pF 2% N330 100VDC PHILIPS 2222 689 46181 16.168
C327 CAPACITOR POLYSTYRENE 180pF 1% 630VDC PHILIPS 2222 431 81801 10.407
C328 CAPACITOR CERAMIC 180pF 2% N330 100VDC PHILIPS 2222 689 46181 16.168
C329 CAPACITOR MKT 10nF 10% 400V SIEMENS B32510-D6103-K000 11.381
C330 CAPACITOR STYROFLEX 47pF 2,5% 160V SIEMENS B31063-B1470-H000 10.168
