6 PARTSLIST RT2047 DSC - PART II
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
9810
PAGE 5-5
C331 CAPACITOR TRIMMING 2-18pF PTFE DAU 107.2901.018 17.100
C332 CAPACITOR CERAMIC 27pF 5% N150 50VDC KCK RT-HE50 SK PH 270 J 15.812
C333 CAPACITOR CERAMIC 12pF 5% NPO 500VDC KCK RT-HM60-SK CH 120 J 15.575
C334 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C335 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C336 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C337 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ERO EKI 00 AA 233 D M5K 14.518
C338 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C339 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C340 CAPACITOR CERAMIC 12pF 5% NPO 500VDC KCK RT-HM60-SK CH 120 J 15.575
C341 CAPACITOR CERAMIC 5p1F +/-0.25pF N150 500V KCK RT-HM60-SK PH 5R1 C 16.107
C342 CAPACITOR CERAMIC 10pF 5% N150 500VDC KCK RT-HM60-SK PH 100 J 16.113
C343 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C344 CAPACITOR CERAMIC 220pF 10% 500VDC CL2 KCK RT-HM60-SK YB 221 K 16.090
C345 CAPACITOR CERAMIC 8p2F +/-0.25pF N150 500V KCK RT-HM60-SK PH 8R2 C 16.112
C346 CAPACITOR ELECTROLYTIC 4.7uF 20% 50VDC ERO EKI 00 AA 147 H M5K 14.510
C347 CAPACITOR MKT 3n3F 5% 400V SIEMENS B32520-B6332-J-289 11.371
C348 CAPACITOR MKT 33nF 5% 250V SIEMENS B32510-D3333-J000 11.497
C349 CAPACITOR CERAMIC 100pF 5% N150 500V #KCK HM11SJPH101J 15.132
C350 CAPACITOR ELECTROLYTIC 1uF 20% 50VDC ERO EKI 00 AA 110 H M5K 14.506
C351 CAPACITOR POLYSTYRENE 8,2nF 1% 160V #PHILIPS 2222 429 88202 10.298
C352 CAPACITOR MKT 10nF 20% 100VDC PHILIPS 2222 370 38103 11.168
C353 CAPACITOR MKT 100nF 10% 100VDC PHILIPS 2222 371 28104 11.219
C354 CAPACITOR ELECTROLYTIC 0.22uF 20% 50VDC ERO EKI 00 AA 022 H M0E 14.502
C355 CAPACITOR MKT 220nF 10% 100V SIEMENS B32510-D1224-K000 11.225
C356 CAPACITOR MKT 10nF 10% 400V SIEMENS B32510-D6103-K000 11.381
D301 DIODE BAW62 HIGH SPEED PHILIPS BAW62-143 25.350
D302 DIODE CAPASITANCE 13pF/9VDC TOSHIBA 1SV101 in matched group 26.135
D303 DIODE BAW62 HIGH SPEED PHILIPS BAW62-143 25.350
FP301 FERRITE BEAD •3,7x•1.2x3.5mm GRADE 3B PHILIPS 4322 020 34400 35.180
FP302 FERRITE BEAD •3.7x•1.2x3.5mm GRADE 4B1 PHILIPS 4322 020 34420 35.181
IC301 INTEGRATED CIRCUIT SN74LS293N FAIRCHILD* 74LS293P 34.260
IC302 INTEGRATED CIRCUIT SN74LS113AN MOTOROLA* SN74LS113AN 33.841
IC303 INTEGRATED CIRCUIT SN74LS10N TEXAS* SN74LS10N 33.534
IC304 INTEGRATED CIRCUIT SN74LS113AN MOTOROLA* SN74LS113AN 33.841
IC305 INTEGRATED CIRCUIT SN74LS113AN MOTOROLA* SN74LS113AN 33.841
IC306 DECADE UP COUNTER SN74LS290N MOTOROLA SN74LS290N 34.251
L301 CHOKE 2.2uH 10% FERROPERM 1582 20.131
L302 CHOKE 15uH 10% FERROPERM 1582 20.152
L303 CHOKE 15uH 10% FERROPERM 1582 20.152
L304 CHOKE 1uH 10% FERROPERM 1582 20.115
L305 CHOKE FIXED 470nH 10% SIEMENS B78108-T3471-K 20.075
L306 COIL TL374 ECI A/S 6-0-23690 400374
L307 COIL TL373 S.P.RADIO 6-0-23689 400373
L308 COIL TL372 ECI A/S 6-0-23688 400372
L309 COIL TL375 ECI A/S 6-0-23696B 400375
L310 COIL TL376 S.P.RADIO 6-0-23697C 400376
L311 CHOKE 4u7H 10% SIEMENS B78108-T1472-K 20.137
R301 RESISTOR MF 47 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-47R 01.666
R302 RESISTOR MF 12 OHM 5% 0.4W PHILIPS 2322 181 53129 01.152
R303 RESISTOR MF 470 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-470R 01.691
R304 RESISTOR MF 2k2 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-2k2 01.708
R305 RESISTOR MF 56 OHM 5% 0.4W PHILIPS 2322 181 53569 01.168
R306 RESISTOR MF 2k2 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-2k2 01.708
R307 RESISTOR MF 82 OHM 5% 0.4W PHILIPS 2322 181 53829 01.172
R308 RESISTOR MF 470 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-470R 01.691
R309 RESISTOR MF 12 OHM 5% 0.4W PHILIPS 2322 181 53129 01.152
R310 RESISTOR MF 1k5 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-1k5 01.704
R311 RESISTOR MF 3k9 OHM 5% 0.4W PHILIPS 2322 181 53392 01.214
R312 RESISTOR MF 1k2 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-1k2 01.702
R313 RESISTOR MF 270 OHM 5% 0.4W PHILIPS 2322 181 53271 01.185
R314 RESISTOR MF 56 OHM 5% 0.4W PHILIPS 2322 181 53569 01.168
R315 RESISTOR MF 2k2 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-2k2 01.708
R316 RESISTOR MF 33 OHM 5% 0.4W PHILIPS 2322 181 53339 01.162
R317 RESISTOR MF 82 OHM 5% 0.4W PHILIPS 2322 181 53829 01.172
R318 RESISTOR MF 560 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-560R 01.693
R319 RESISTOR MF 3k3 OHM 5% 0.4W PHILIPS 2322 181 53332 01.212
R320 RESISTOR MF 1k0 OHM 5% 0.4W PHILIPS 2322 181 53102 01.200
R321 RESISTOR MF 47k OHM 5% 0.4W PHILIPS 2322 181 53473 01.241
R322 RESISTOR MF 2k2 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-2k2 01.708
R323 RESISTOR MF 1k0 OHM 5% 0.4W PHILIPS 2322 181 53102 01.200
R324 RESISTOR MF 3k3 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-3k3 01.712
R325 RESISTOR MF 390 OHM 5% 0.4W S BEYSCHLAG MUB 0207-50-5%-390R 01.689
R326 RESISTOR MF 150 OHM 5% 0.4W PHILIPS 2322 181 53151 01.179
