Sailor RT2048 VHF User Manual

RT2048
Squelch Read-out
Loudspeaker On/Off/Vol
Loudspeaker Keyboard (module 1) Thread for cover allen screw
Antenna connectorPower connector for 12V or N420
Thread for cover
allen screw
Fuse cover with
spare-fuse
Microphone connector
Strap for connection
to N420 (24V)
Strap for connection
to external sypply
(12V)
Selcall Unit (module 5)
Interface Unit (module 2)
Rx/Tx Unit (module 4)
Synthesizer Unit (module 3)
Synthesizer Unit
Rx/Tx Unit
Selcall Unit
Cable to Keyboard Unit
Interface Unit
Loudspeaker
Page 4-1
4. MODULE LOCATION
RT2048A
4-6-25561, 62, 64, 65, 66, 67
