6 MICROTELEPHONE INSTALLATION RT2048
MICROTELEPHONE WITH ELECTRET MIC. AMP. ECI A/S 4-6-24025D/4-0-24025E 600875
POSITION DESCRIPTION MANUFACTOR TYPE PART NR.
C1 CAPACITOR ELECTROLYTIC 100uF 20% 10VDC ERO EKI 00 BB 310 C M0E 14.607
C2 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C3 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ELNA RJ2-35-V-100-M-T34(T58) 14.512
C4 CAPACITOR ELECTROLYTIC 0.47uF 20% 50VDC ELNA RJ3-50-V-R47-M-T34 14.504
C5 CAPACITOR ELECTROLYTIC 2u2F 20% 50VDC ELNA RJ2-50-V-2R2-M-T34 14.503
C6 CAPACITOR ELECTROLYTIC 2u2F 20% 50VDC ELNA RJ2-50-V-2R2-M-T34 14.503
C7 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ELNA RJ2-35-V-100-M-T34(T58) 14.512
C8 CAPACITOR CERAMIC CL2 1n0F 10% 100V PHILIPS 2222 630 63102 16.149
C9 CAPACITOR CERAMIC CL2 1n0F 10% 100V PHILIPS 2222 630 63102 16.149
C10 CAPACITOR ELECTROLYTIC 33uF 20% 16VDC ELNA RJ2-16-V-330-M-T34 14.518
C11 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C12 CAPACITOR CERAMIC 27pF 10% N750 500VDC KCK RT-HM60-SK UJ 270 K 16.062
C13 CAPACITOR CERAMIC 27pF 10% N750 500VDC KCK RT-HM60-SK UJ 270 K 16.062
C14 CAPACITOR CERAM. SMD 0805 15pF 5% NPO 50VDC MURATA GRM40 COG 150 J 50 PT 323.076
D1 DIODE 1N4148 HIGH SPEED PHILIPS 1N4148-143 25.131
MC1 MICROPHONE ELECTRET ›9.7 x 6.7mm PANASONIC WM-0344BY 46.012
R1 RESISTOR MF 1k8 OHM 5% 0.33W PHILIPS 2322 187 73182 02.478
R2 RESISTOR MF 1k8 OHM 5% 0.33W PHILIPS 2322 187 73182 02.478
R3 RESISTOR MF 8k2 OHM 5% 0.33W PHILIPS 2322 187 73822 02.494
R4 RESISTOR MF 18k OHM 5% 0.33W PHILIPS 2322 187 73183 02.502
R5 RESISTOR MF 2k7 OHM 5% 0.33W PHILIPS 2322 187 73272 02.482
R6 RESISTOR MF 4k7 OHM 5% 0.33W PHILIPS 2322 187 73472 02.488
R7 RESISTOR MF 2k2 OHM 5% 0.33W PHILIPS 2322 187 73222 02.480
R8 RESISTOR MF 6k8 OHM 5% 0.33W PHILIPS 2322 187 73682 02.492
R9 RESISTOR MF 2k7 OHM 5% 0.33W PHILIPS 2322 187 73272 02.482
R10 RESISTOR MF 120k OHM 5% 0.33W PHILIPS 2322 187 73124 02.522
R11 RESISTOR MF 39k OHM 5% 0.33W PHILIPS 2322 187 73393 02.510
S1 MICROSWITCH E62-10H PDT CHERRY E62-10H PDT 44.025
T1 TRANSISTOR AF NPN BC547C TO-92 PHILIPS BC547C-126 28.068
T2 TRANSISTOR AF NPN BC547C TO-92 PHILIPS BC547C-126 28.068
T3 TRANSISTOR AF NPN BC547C TO-92 PHILIPS BC547C-126 28.068
TC1 TRANSDUCER DYNAMIC FOR HANDSET •31x18mm 200 OHM S.E.K. (KIRK) T802 0113 2715 46.010
9649
Page 6-2
