Sailor RT2048 VHF User Manual

7 PARTS LIST RT2048
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
C12-3 CAPACITOR ELECTROLYTIC 47uF 20% 25VDC ELNA RJ2-25-V-470-M-F1 14.524
C13-3 CAPACITOR MKT 220nF 5% 63VDC PHILIPS 2222 370 79224 11.182
C14-3 CAPACITOR ELECTROLYTIC 22uF 20% 35VDC ELNA RJ2-35-V-220-M-F1 14.516
C15-3 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ELNA RJ2-35-V-100-M-T34(T58) 14.512
C16-3 CAPACITOR ELECTROLYTIC 4.7uF 20% 50VDC ELNA RJ2-50-V-4R7-M-T34 14.510
C17-3 CAPACITOR MKT 1u5F 10% 50VDC ERO MKT 1826 515/05 5-G 11.191
C18-3 CAPACITOR POLYSTYRENE 12n1F 1% 63VDC PHILIPS 2222 443 41213 10.796
C19-3 CAPACITOR ELECTROLYTIC 1uF 20% 50VDC ELNA RJ2-50-V-010-M-T34 14.506
C20-3 CAPACITOR CERAMIC 39pF 5% NPO 50VDC KCK RT-HE50 SK CH 390 J 15.085
C21-3 CAPACITOR CERAMIC 5p6F +/-0.25pF NPO 500VDC KCK RT-HM60 SK CH 5R6 C 15.015
C22-3 CAPACITOR CERAMIC 1nOF 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
C23-3 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C24-3 CAPACITOR CERAMIC 6p8F +/-0.25pF NPO 100VDC PHILIPS 2222 689 09688 15.325
C25-3 CAPACITOR CERAMIC 1nOF 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
C26-3 CAPACITOR CERAMIC 1nOF 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
C27-3 CAPACITOR CERAMIC 1nOF 10% CL2 500VDC KCK RT-HM60 SK YB 102 K 15.160
C28-3 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C29-3 CAPACITOR MKT 1uF 5% 63VDC ERO MKT 1826-510/06 4-G 11.190
C30-3 CAPACITOR MKT 470nF 5% 63VDC ERO MKT 1826-447/06 4-G 11.187
C31-3 CAPACITOR MKT 22nF 5% 100VDC PHILIPS 2222 370 89223 11.169
C32-3 CAPACITOR ELECTROLYTIC 47uF 20% 25VDC ELNA RJ2-25-V-470-M-F1 14.524
C33-3 CAPACITOR CERAMIC 100pF 5% NPO 50VDC KCK RT-HE80 SK CH 101 J 15.136
C34-3 CAPACITOR POLYSTYRENE 825pF 1% 63VDC PHILIPS 2222 443 48251 10.755
C35-3 CAPACITOR MKT 150nF 5% 50VDC ERO MKT 1826-415/06 4-G 11.181
C36-3 CAPACITOR MKT 68nF 5% 63VDC PHILIPS 2222 370 79683 11.178
C37-3 CAPACITOR MKT 1uF 10% 63VDC ERO MKT 1826-510/06 5-G 11.137
C38-3 CAPACITOR POLYSTYRENE 12n1F 1% 63VDC PHILIPS 2222 443 41213 10.796
C39-3 CAPACITOR POLYSTYRENE 221pF 1% 63VDC PHILIPS 2222 443 42211 10.727
C41-3 CAPACITOR ELECTROLYTIC 47uF 20% 25VDC ELNA RJ2-25-V-470-M-F1 14.524
C42-3 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C43-3 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C44-3 CAPACITOR ELECTROLYTIC 100uF -10/+50% 25VDC ERO EKM 00 CC 310 E G5 14.610
C45-3 CAPACITOR MKT 330nF 5% 63VDC ERO MKT 1826-433/06 4-G 11.184
C46-3 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C47-3 CAPACITOR CERAMIC 15pF 5% N150 500VDC KCK RT-HM60 SK PH 150 J 16.115
C48-3 CAPACITOR CERAMIC 22pF 5% N150 500VDC KCK RT-HM SK PH 220 J 15.062
C49-3 CAPACITOR CERAMIC 13pF 5% N150 50VDC KCK RT-HE40 SK PH 130 J 15.051
C50-3 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C51-3 CAPACITOR CERAMIC 2p7F +/-0.25pF N150 50VDC KCK RT-HE40 SK PJ 2R7 C 15.001
C52-3 CAPACITOR CERAMIC 18pF 5% NPO 500VDC KCK RT-HM60 SK CH 180 J 15.060
C53-3 CAPACITOR CERAMIC 18pF 5% NPO 500VDC KCK RT-HM60 SK CH 180 J 15.060
C54-3 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C55-3 CAPACITOR CERAMIC 12pF 5% NPO 500VDC KCK RT-HM60-SK CH 120 J 15.575
C56-3 CAPACITOR CERAMIC 8p2F +-0.25pF NPO 500VDC KCK RT-HM60 SK 8R2 C 15.030
C57-3 CAPACITOR CERAMIC 18pF 5% NPO 500VDC KCK RT-HM60 SK CH 180 J 15.060
C58-3 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C59-3 CAPACITOR CERAMIC 18pF 2% NPO 100VDC PHILIPS 2222 689 10189 15.330
C60-3 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C61-3 CAPACITOR CERAMIC 12pF 2% NPO 100VDC PHILIPS 2222 689 10129 15.328
C62-3 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C63-3 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ELNA RJ2-35-V-100-M-T34(T58) 14.512
C64-3 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C65-3 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C66-3 CAPACITOR CERAMIC 15pF 2% NPO 100VDC PHILIPS 2222 689 10159 15.329
C67-3 CAPACITOR CERAMIC 15pF 2% NPO 100VDC PHILIPS 2222 689 10159 15.329
C68-3 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C69-3 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C70-3 CAPACITOR CERAMIC 12pF 2% NPO 100VDC PHILIPS 2222 689 10129 15.328
C71-3 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C72-3 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C73-3 CAPACITOR CERAMIC 33pF 2% NPO 100VDC PHILIPS 2222 689 10339 15.333
C74-3 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ELNA RJ2-35-V-100-M-T34(T58) 14.512
C75-3 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ELNA RJ2-35-V-100-M-T34(T58) 14.512
C76-3 CAPACITOR ELECTROLYTIC 220uF -20/+50% 16VDC ELNA RJ2-16-V-221-M-T2 14.640
C77-3 CAPACITOR TRIMMING 3.9-27pF PTFE DAU 107.3901.027 17.110
C78-3 CAPACITOR TRIMMING 1.8-9pF PTFE DAU 117 1991 009 B021 17.090
C79-3 CAPACITOR MKT 220nF 10% 63VDC PHILIPS 2222 370 78224 11.095
C80-3 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 78104 11.136
D1-3 DIODE BAW62 HIGH SPEED PHILIPS BAW62-143 25.350
D2-3 DIODE 1N4150 PHILIPS 1N4150 25.140
D3-3 DIODE SCHOTTKY BAT 43 THOMSON-CSF BAT43 27.600
D4-3 DIODE BAW62 HIGH SPEED PHILIPS BAW62-143 25.350
D5-3 DIODE 1N4148 HIGH SPEED PHILIPS 1N4148-143 25.131
0820
Page 7-9
