Sailor RT2048 VHF User Manual

7 PARTS LIST RT2048
POSITION DESCRIPTION MANUFACTOR TYPE PART NO.
C71-3 CAPACITOR CERAMIC 470pF 10% 500VDC KCK RT-HM60 SK YB 471 K 16.095
C72-3 CAPACITOR CERAMIC 10nF -20/+80% CL2 50VDC KCK RT-HE70 SK YF 103 Z 15.170
C73-3 CAPACITOR CERAMIC 33pF 2% NPO 100VDC PHILIPS 2222 689 10339 15.333
C74-3 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ELNA RJ2-35-V-100-M-T34(T58) 14.512
C75-3 CAPACITOR ELECTROLYTIC 10uF 20% 35VDC ELNA RJ2-35-V-100-M-T34(T58) 14.512
C76-3 CAPACITOR ELECTROLYTIC 220uF -20/+50% 16VDC ELNA RJ2-16-V-221-M-T2 14.640
C77-3 CAPACITOR TRIMMING 3.9-27pF PTFE DAU 107.3901.027 17.110
C78-3 CAPACITOR TRIMMING 1.8-9pF PTFE DAU 117 1991 009 B021 17.090
C79-3 CAPACITOR MKT 220nF 10% 63VDC PHILIPS 2222 370 78224 11.095
C80-3 CAPACITOR MKT 0.1uF 10% 63VDC PHILIPS 2222 370 78104 11.136
D1-3 DIODE BAW62 HIGH SPEED PHILIPS BAW62-143 25.350
D2-3 DIODE 1N4150 PHILIPS 1N4150 25.140
D3-3 DIODE SCHOTTKY BAT 43 THOMSON-CSF BAT43 27.600
D4-3 DIODE BAW62 HIGH SPEED PHILIPS BAW62-143 25.350
D5-3 DIODE 1N4148 HIGH SPEED PHILIPS 1N4148-143 25.131
D6-3 DIODE SWITCH FACTORY SELECTED MPN 3700 T&T A/S C1082A / 0-0-25550 725550
D7-3 DIODE SWITCH BA282 TFK BA 282 TAPED 25.390
D8-3 DIODE SWITCH BA282 TFK BA 282 TAPED 25.390
D9-3 DIODE CAPASITANCE 13pF/9VDC TOSHIBA 1SV101 in matched group 26.135
D10-3 DIODE SCHOTTKY BAT 43 THOMSON-CSF BAT43 27.600
J1-3 SOCKET COAX FOR PCB 45 DEG. HORIZONTAL TAIKO TMP-J01X-A2 78.517
J2-3 SOCKET COAX FOR PCB 45 DEG. HORIZONTAL TAIKO TMP-J01X-A2 78.517
J3-3 SOCKET COAX FOR PCB 45 DEG. HORIZONTAL TAIKO TMP-J01X-A2 78.517
J4-3 SOCKET COAX FOR PCB 45 DEG. HORIZONTAL TAIKO TMP-J01X-A2 78.517
L1-3 CHOKE 0.10uH 5% WEST CAP 1A1003M-5% / TAPED 20.099
L2-3 COIL TL371 T&T A/SIO 6-0-23687 400371
L3-3 CHOKE 4u7H 10% SIEMENS B78108-T1472-K 20.137
L4-3 CHOKE 4u7H 10% SIEMENS B78108-T1472-K 20.137
L5-3 CHOKE 4u7H 10% SIEMENS B78108-T1472-K 20.137
L6-3 CHOKE 0.10uH 5% WEST CAP 1A1003M-5% / TAPED 20.099
L7-3 CHOKE 0.10uH 5% WEST CAP 1A1003M-5% / TAPED 20.099
L8-3 CHOKE 0.10uH 5% WEST CAP 1A1003M-5% / TAPED 20.099
L9-3 TRANSFORMER RF 110nH ADJUSTABLE TOKO E526-110436 38.407
L10-3 CHOKE TL489 T&T A/S 6-0-25459 400489
L11-3 CHOKE TL491 T&T A/S 6-0-25461 400491
L12-3 CHOKE TL491 T&T A/S 6-0-25461 400491
L13-3 CHOKE TL489 T&T A/S 6-0-25459 400489
L14-3 CHOKE TL490 T&T A/S 6-0-25460 400490
P1-3 PLUG PCB 2x5 POLES RIGHT ANGLE 3M 7610-5002-JL 78.252
Q1-3 TRANSISTOR BF 324 PHILIPS BF324 28.204
Q2-3 TRANSISTOR RF BF199 PHILIPS BF199 28.178
Q3-3 TRANSISTOR RF SWITCH 2N2369A MOTOROLA 2N2369A 28.315
Q4-3 TRANSISTOR AF BC548B NPN TO-92 PHILIPS BC548B 28.076
Q5-3 TRANSISTOR AF BC558B PHILIPS BC558B 28.100
Q6-3 TRANSISTOR AF BC338-25 NPN TO-92 PHILIPS BC338-25 28.058
Q7-3 TRANSISTOR RF LOW POWER PNP BF979 TELEFUNKEN AG BF979 28.251
Q8-3 TRANSISTOR AF BC558B PHILIPS BC558B 28.100
Q9-3 TRANSISTOR AF BC548B NPN TO-92 PHILIPS BC548B 28.076
Q10-3 TRANSISTOR BC549C PHILIPS BC549C 28.082
Q11-3 TRANSISTOR BC549C PHILIPS BC549C 28.082
Q12-3 TRANSISTOR AF BC548B NPN TO-92 PHILIPS BC548B 28.076
Q13-3 TRANSISTOR RF NPN TO-39 Central semi NPN TO-39 26-204715-427
Q14-3 TRANSISTOR RF BFW92A TFK BFW92A 29.160
Q15-3 TRANSISTOR RF LOW POWER PNP BF979 TELEFUNKEN AG BF979 28.251
Q16-3 TRANSISTOR RF BFW92A TFK BFW92A 29.160
Q17-3 TRANSISTOR JFET N CHANNEL BF245A MOTOROLA BF245A 29.714
Q18-3 TRANSISTOR JFET N-CHAN. J309 SILICONIX J309 29.724
R1-3 RESISTOR MF 20k0 OHM 1% 0.6W PHILIPS 2322 156 12003 03.452
R2-3 RESISTOR MF 60k4 OHM 1% 0.6W PHILIPS 2322 156 16043 03.238
R3-3 RESISTOR MF 33k2 OHM 1% 0.6W PHILIPS 2322 156 13323 03.232
R4-3 RESISTOR MF 100k OHM 1% 0.6W PHILIPS 2322 156 11004 03.477
R5-3 RESISTOR MF 221k OHM 1% 0.6W PHILIPS 2322 156 12214 03.483
R6-3 RESISTOR MF 47k OHM 5% 0.4W PHILIPS 2322 181 53473 01.241
R7-3 RESISTOR MF 6k8 OHM 5% 0.4W PHILIPS 2322 181 53682 01.220
R8-3 RESISTOR MF 220 OHM 5% 0.4W PHILIPS 2322 181 53221 01.183
R9-3 RESISTOR MF 33 OHM 5% 0.4W PHILIPS 2322 181 53339 01.162
R10-3 RESISTOR MF 82 OHM 5% 0.4W PHILIPS 2322 181 53829 01.172
R11-3 RESISTOR MF 12k OHM 5% 0.4W PHILIPS 2322 181 53123 01.227
R12-3 RESISTOR MF 18k OHM 5% 0.4W PHILIPS 2322 181 53183 01.231
R13-3 RESISTOR MF 51 OHM 5% 0.4W PHILIPS 2322 181 53519 01.167
R14-3 RESISTOR MF 8k2 OHM 5% 0.4W PHILIPS 2322 181 53822 01.222
R15-3 RESISTOR MF 3k3 OHM 5% 0.4W PHILIPS 2322 181 53332 01.212
R16-3 RESISTOR MF 2k0 OHM 5% 0.4W PHILIPS 2322 181 53202 01.207
0820
Page 7-13
