R5 Series
- 18 -
Grid Monitoring
Integrated
AC Short Circuit Current Protection
Integrated
AC grounding detection
Integrated
DC Surge Protection
Integrated
AC Surge Protection
Integrated
Thermal Protection
Integrated
Anti-island Protection Monitoring
AFD
Interface
AC Connection
Terminal Block
DC Connection
MC4
Human Machine Interface
LED+(Bluetooth/Wi-Fi+APP)
Communication Port
RS232(USB)+RS485(RJ45)
Communication Mode
Wi-Fi/GPRS/4G(Optional)
General Data
Topology
Transformerless
Consumption at Night [W]
<0.2
Consumption at Standby [W]
6
Operating Temperature Range
-40℃～+60℃[45°C to 60°C with derating]
Cooling Method
Natural Convection
Ambient Humidity
0-100% Non-condensing
Altitude
4000m(>3000m power derating)
Noise [dBA]
<25
Ingress Protection
IP65
Mounting
Rear Panel
Dimensions [H*W*D][mm]
429*418*177
Weight [kg]
18
Standard Warranty [Year]
5(standard)/10/15/20/25(Optional)
Applicable Standard
CQC NB/T 32004, EN62109-1/2, EN61000-6-1/2/3/4,
EN50438, EN50549, IEC62116, IEC61727, RD1699,
UNE206006, UNE206007-1, CEI0-21,G99
Note: 1. Meet the VDE - ARN - N 4105 that biggest apparent power of single-phase is 4600 VA.
2. Applicable to Belgian grid standard.
3. The above parameters might be slightly modified according to different grid codes.
4. If you need more information about our product certifications, please contact our sales.
