Page #17 background image
VM600
- 16 -
Parameter
Name
Setting Range
Default
Property
Address
F5.14
DI1 Disable Delay Time
0.0s100.0s
0.0s
050E
F5.15
DI2 Disable Delay Time
0.0s100.0s
0.0s
050F
F5.16
AI Input Digital Functional
Option
0: No function
1: Forward running (FWD)
2: Reverse running (REV)
3: Three-wire operation control
4: Forward point movement (FJOG)
5: Reverse point movement (RJOG)
6:Error Reset
7:Terminal UP
8:Terminal Down
9:UP/DOWN Setting Clear
10:External error input(Normally Open)
11PLC Status reset
12:Multi stage speed terminal 1
13: Multi stage speed terminal 2
14:Reserved
0
0510
F5.17
AI Input Valid Level Option
0Low Level Valid
1High Level Valid
1
0511
F6.00
Relay Output Option
0No Output
1VFD Running
2Error Output(Output is valid only after
VFD stops)
3Ready for Running
4Communication Setting
5: User Defined Output
0
0600
F6.01
Relay1 Closed Delay Time
0.0s100.0s
0.0s
0601
F6.02
Relay1 Open Delay Time
0.0s100.0s
0.0s
0602
F6.03
User defined output
Variability optionEX
0Running Frequency
1Set Frequency
2Bus Voltage
3Output Voltage
4Output Current
0
0603
F6.04
User defined comparison
method
Units digitcomparison test
method
0: Equal (EX==X1)
1: Equal or greater than
2: Equal or less than
3 Interval comparison
(X1≤EX≤X2)
4:Units digit test (EX&X1=X2)
Tens digit: output method
0: False value output
1: Real value output
0
0604
F6.05
User defined output dead
065535
0
0605
