SAJ VM600 User Manual

VM600
- 15 -
Parameter
Name
Setting Range
Default
Property
Address
F3.05
Multi-Point Frequency 3
F3.05~F2.02（Motor Rated Frequency）
8
●
0305
F3.06
Multi-Point Voltage 3
0.0%~100.0%
22
●
0306
F4.00
Torque Boost
0.0%～30.0%
4.0%
○
0400
F4.01
Cut-off frequency of torque
boost
0.00Hz～F0.05
50.00Hz
●
0401
F4.02
Trigging frequency of DC
braking at stop
0.00Hz～F0.05
0.00Hz
○
0402
F4.03
Delay time of DC braking at
stop
0.0s～50.0s
0.0s
○
0403
F4.04
The current of DC braking
at stop
0～100%
0
○
0404
F4.05
The time of DC braking at
stop
0.0s～50.0s
0.0s
○
0405
F4.06
Automatic adjustment of
carrier Frequency
0:Invalid; 1:Valid
0
●
0406
F4.07
0 frequency output option
0:Valid; 1:Invalid
1
●
0407
F5.00
DI1 terminal function
selection
0: No function
1: Forward running (FWD)
2: Reverse running (REV)
3: Three-wire operation control
4: Forward point movement (FJOG)
5: Reverse point movement (RJOG)
6:Error Reset
7:Terminal UP
8:Terminal Down
9:UP/DOWN Setting Clear
10:External error input(Normally Open)
11：PLC Status reset
12:Multi stage speed terminal 1
13: Multi stage speed terminal 2
14:Reserved
1
●
0500
F5.01
DI2 terminal function
selection
2
●
0501
F5.02
DI3 terminal function
selection
6
●
0502
F5.03
DI4 terminal function
selection
0
●
0503
F5.04
DI filter time
0.000s～1.000s
0.010s
○
0504
F5.05
Terminal Command Option
0: Two-line mode 1
1: Two-line mode 2
2: Three-line mode 1
3: Three-line mode 2
0
●
0505
F5.06
UP/DOWN change rate
range
0.01Hz～50.00Hz
0.50Hz
○
0506
F5.07
AI minimum input
0.00V～F5.09
0.00V
○
0507
F5.08
Percentage rate of AI
minimum input
-100.0%～+100.0%
0.0%
○
0508
F5.09
AI maximum input
F5.07～+10.00V
10.00V
○
0509
F5.10
Percentage rate of AI
maximum input
-100.0%～+100.0%
100.0%
○
050A
F5.11
AI filter time
0.00s～10.00s
0.10s
○
050B
F5.12
DI1 Enable Delay Time
0.0s～100.0s
0.0s
○
050C
F5.13
DI2 Enable Delay Time
0.0s～100.0s
0.0s
○
050D
