5.3 Description of Keys on the Operation Panel
Key Name Function
PROG Programming Enter or exit Level I menu.
M-FUN
Multifunction
Selection
Function switch selection. It can be dened as a
command source, or as a fast direction switch,
according to P7-01.
▲ Increment Increase data or function code.
▼ Decrement Decrease data or function code.
SHIFT Shift
Select the displayed parameters in turn in the stop
or running state, and select the digit to be modied
when modifying parameters.
ENTER Conrm
Enter the menu interfaces level by level, and conrm
the parameter setting.
RUN Run
Start the AC drive in the operation panel control
mode.
STOP Stop
Stop the AC drive when it is in the running state and
perform the reset operation when it is in the fault
state. The functions of this key are restricted in P7-
02.
