20
Pre-installation
Installation
PumpWise guidelines
General specification
Trouble shooting
PumpWise and warranty
Pump Model RP50PT RP75PT RP100PT RP55PS RP80PS RP120PS
General Guarantee 2 Years
Features Pump Type Centrifugal
Mechanical Seal Nitrile/Carbon/Ceramic
Inlet Isolator(s) • • • • • •
Flexible Hoses 4 4 4 2 2 2
Dry Run Protection
Performance Pressure @ 16lpm 1.0 bar 1.2 bar 2.7 bar 1.0 bar 1.8 bar 3.0 bar
Pressure @ 8lpm 1.2 bar 1.6 bar 2.9 bar 1.2 bar 2.1 bar 3.3 bar
Pressure @ Closed head 1.5 bar 2.0 bar 3.1 bar 1.5 bar 2.4 bar 3.6 bar
Maximum Water Temperature 60°C
Connections Pump Connections 3/4” BSP
Flexible hoses Connections (UK Model) 3/4 Female x 22mm push-Fit x 280mm long, isolating valves on all hoses
Motor Type A.C Induction Motor
Duty Rating Continuously Rated
Elecrical Power supply 230 V
Current (full load) 1.30 amps 3.10 amps 4.40 amps 1.20
amps
1.70 amps 2.20 amps
Power consumption 320 watts 740 watts 1050 watts 250 watts 400 watts 520 watts
Fuse rating 3 amps 5 amps 3 amps
Power cable (pre-wired) 1.5 metres
Physical Enclosed Protection (IP Rating) IPX2
Length 260mm 330mm 415mm 240mm 265mm 290mm
Width 145mm
Height (Excluding hoses) 155mm
Weight (Excluding hoses) 4.9kg 6.6kg 9.7kg 5.7kg 6.0kg 6.3kg
