Pump Model RP50TU RP75TU RP100TU RP55SU RP80SU RP120SU
General Guarantee 2 Years
Features Pump Type Centrifugal
Mechanical Seal Nitrile/Carbon/Ceramic
Inlet Isolator(s) • • • • • •
Flexible Hoses 4 4 4 2 2 2
Dry Run Protection • • • • • •
Performance Pressure @ 16lpm 1.0 bar 1.6 bar 2.5 bar 1.0 bar 1.9 bar 2.9 bar
Pressure @ 8lpm 1.2 bar 1.9 bar 2.8 bar 1.3 bar 2.1 bar 3.2 bar
Pressure @ Closed head 1.5 bar 2.1 bar 3.0 bar 1.5 bar 2.3bar 3.4 bar
Maximum Water Temperature 60°C
Pressure Vessel Air Pre-Charge 8 psi 14 psi 20 psi 8 psi 14 psi 20 psi
Connections Pump Connections 3/4” BSP
Flexible hoses Connections (UK Model) 3/4 Female x 22mm push-Fit x 280mm long, isolating valves on all hoses
Motor Type A.C Induction Motor
Duty Rating Continuously Rated
Elecrical Power supply 230 V
Current (full load) 1.30 amps 2.70 amps 4.50 amps 1.20 amps 1.70 amps 2.20 amps
Power consumption 320 watts 640 watts 1050
watts
250 watts 400 watts 500 watts
Fuse rating 3 amps 5 amps 3 amps
Power cable (pre-wired) 1.5 metres
Physical Enclosed Protection (IP Rating) IPX2
Length 260mm 320mm 400mm 240mm 265mm 290mm
Width 220mm
Height (Excluding hoses) 180mm
Weight (Excluding hoses) 5.9kg 7.2kg 10.3kg 6.1kg 6.5kg 6.7kg
