SALCOR INC
Page 11 of 14
The Printed Circuit Alarm Board is permanently mounted on the Junction Box Lid. The
power and alarm terminal blocks are mounted on the Printed Circuit Alarm Board.
The ballast is mounted on the Printed Circuit Board. When necessary, an inoperative
ballast may be replaced by qualified maintenance personnel.
Note: N/O or N/C describes the contact configuration when there is
NO POWER APPLIED to the relay.
Another way of designating the N/O or N/C condition is that the
relay contacts are Normally Open or are Normally Closed when the
relay is: NOT ENERGIZED!
1. Connect the alarm wires as needed for your specific alarm circuit requirements to
Alarm Board TB5
2. Connect the power wires to the Power Inlet Terminal Block, TB4. The Terminal
Block is labeled with connection points for the com and hot wires. The ground wire
connects to the ground stud on the ballast.
VI. DECLARATION OF CONFORMITY
Salcor Inc. declares that the Salcor Model 3G UV Disinfection Unit conforms to the
applicable provisions of the Code of Federal Regulations (CFR) requirements including,
Title 21, Chapter 1, Subchapter J, Radiological Health.
VII. PARTS LIST FOR SALCOR MODEL 3G UV UNIT
New Electrical Subassembly: Includes NEMA 6P Junction Box with Printed
Wiring Alarm Board and Ballast Mounted on the NEMA 6P Junction Box Lid,
a Lamp Cable, and a UL Waterproof Electrical Conduit Fitting
Lamp Ballast Test Unit for Onsite Ballast Testing. Includes Test Cable, Small
Non-UV Test Lamp. Lamp Will Connect to Presently Installed Lamp Cable.
