Salda Stouch - Page 19

EN | 19STOUCH v2019.1
SET Fan speed (%) 0,20 - 100
Holding
register
0x30 45
SET Fan speed xed 0 - 4
Holding
register
0x31 46
SET Pressure 0 – 999 Pa
Holding
register
0x32 47
Display supply temperature - 500 – 1000 (/10)
Holding
register
0x34 48
Save parameters
0: No
22: Yes
Holding
register
0x36 49
0..10 VDC holdback 0 – 120
Holding
register
0x37 50
0..10 VDC Disable / Enable
0: OFF
1: ON
Holding
register
0x38 51
Current fan speed (%) 0 – 100 %
Input
register
0x01 1
Current xed fan speed 0 – 4
Input
register
0x02 2
Temperature Setpoint 150 – 350 °C (/10)
Input
register
0x03 3
Current Temperature - 500 – 1000 (/10)
Input
register
0x04 4
Pressure Setpoint 0 – 999 Pa
Input
register
0x05 5
Current pressure 0 – 999 Pa
Input
register
0x06 6
CO
2
Setpoint 0 – 999 ppm
Input
register
0x07 7
Current CO
2
0 – 999 ppm
Input
register
0x08 8
Alarm 1 address 0/1 Coil 0x01 1
Alarm 2 address 0/1 Coil 0x02 2
Alarm 3 address 0/1 Coil 0x03 3
Alarm 4 address 0/1 Coil 0x04 4
Alarm 5 address 0/1 Coil 0x05 5
Alarm 6 address 0/1 Coil 0x06 6
Alarm 7 address 0/1 Coil 0x07 7
Alarm 8 address 0/1 Coil 0x08 8
Alarm 9 address 0/1 Coil 0x09 9
Alarm 10 address 0/1 Coil 0x0A 10
To save conguration parameters, write 22 to the register 49, then settings are saved to
EEPROM memory, controller reloads.
