EN | 3STOUCH v2019.1
1. DESCRIPTION
Stouch controller is specially designed for control of:
• Heat recovery systems, where control boards PRV_V2
1
, EKR, MCB or ECO_v107
2
are installed;
• Air supply, exhaust units when automatic control is used with ECO_v107 controller;
• Fans with EC motors³;
• Devices which are controlled using Modbus protocol.
1
Units: RIS/RIRS 3.0; RIS/RIRS EKO 3.0
2
Units: RIRS 200 VER EKO; RIRS 300 VE... EKO
3
Using the remote controller “Stouch” for “ECO” fans’ control it is necessary to use additional power
supply and to provide the protection against overloads and/or short circuits.
NOTE: Remote controllers don’t control cooker hoods separately with following units:
RIRS 200 V EKO with “Aut. RIRS-200VEEC-...k (+ 15..25
o
C)” automatics;
RIRS 300 V EKO with “Automatika RIRSV 300 VE” automatics.
This function is possible only with the units that have integrated automatics.
Remote controllers ensures comfortable operation, monitoring, maintenance and safety. All opera-
tions are performed remotely by using controller, which shows fault reports and maintenance con-
ditions.
Features:
• Exceptional and ergonomic design;
• Casing: plastic;
• Screen: tempered glass;
• Easy operation;
• Surface mounted;
• One touch control;
• Easily controlled;
• Numbers displayed at screen;
• Acoustic response to touch;
• Can be connected to BMS network;
• Can be directly connected to fan controlled with 0 - 10 VDC signal;
• CO
2
or pressure sensor can be connected by using 0 - 10 VDC output;
• 4 selectable speeds;
• Maximum fan speed for limited time period (boost);
• Blocking (locking) - protection from children;
• In the user menu, parameters of sound, standby menu and CO
2
can be changed.
Package includes:
Stouch controller, cable (13 m), fastening elements (screw 3,9 x 25 DIN 7981-2 pcs. nylon plug 5 x
25 - 2 pcs., hammered steel plug 12 x 30 - 2 pcs.), technical manual.
