Desktop Reader Manual V2.1
26/02/2007
6/11
MODE Notes Data Interface Format
11001001 ROM WIEGAND 56-bit + 2 parity-
bits
11001010 1 WIEGAND-CODE WIEGAND Format defined in
ProAccess
software
11001011 1, 2 Facility Code zero (8
bits) plus the two lower
bytes of the Serial
Number (16 bits) plus
two parity bits.
WIEGAND Standard 26-bit
11001100 1, 2 Three lower bytes of the
Serial Number (24 bits)
plus two parity bits.
WIEGAND
Standard 26-bit
(1) Only available from firmware version 02.01.
(2) Only valid for Mifare, Desfire and Vicinity cards.
(3) Used not very often. Kept only for backward compatibility purpouses.
7 Data
There are three types of data to be read by the Desktop Reader (or Wall Reader Adaptor):
ROM code or Serial Number This is a factory programmed code particular for each card
TRACKS Emulates the Tracks 1, 2 and 3 of the magnetic stripe cards.
WIEGAND CODE Emulates de Wiegand code of access control cards
7.1 ROM code
The Salto ROM code is a 7 byte code different for each card. Normally each byte is expressed as a
double hexadecimal character so the total ROM code will be 14 ASCII characters (called ROM14). If the
bytes are represented by their 8 bits the total 56 bits representation is called ROM56.
Example:
Format ROM
6
ROM
5
ROM
4
ROM
3
ROM
2
ROM
1
ROM
0
Bytes 0x11 0x22 0x33 0x44 0x55 0x66 0x77
ROM14 “11223344556677”
ROM56 00010001001000100011001101000100010101010110011001110111
7.1.1 ROM code and Serial Number
The relation between the ROM code and the card Serial Number depends on the technology of the card.
This table shows the
ROM6 ROM5 ROM4 ROM3 ROM2 ROM1 ROM0
iButton FamilyCode SN5 SN4 SN3 SN2 SN1 SN0
Smart Card
SLE4442
SLE5542
ICCF2 ICCF3 ICCF4 ICCSN0 ICCSN1 ICCSN2 ICCSN3
