PRODUCT SPECIFICATION
Model: RT505TX
Type: Electronic programmable thermostat,
designed for RF heating applications.
Frequency 868 MHz
Programming
Programming Modes: User selectable for 5/2 or 7 day option
Number of Programmes: Five (5) user programmes plus factory
default programme.
Override Facility: User selectable programme override facility.
Default Programmes
Programme Output Weekday Weekend
1 ON 6:00 AM 6:00 AM
TEMP 21 ºC 21 ºC
2 ON 8:00 AM 8:00 AM
TEMP 14 ºC 14 ºC
3 ON 4:00 PM 4:00 PM
TEMP 21 ºC 21 ºC
4 ON 6:00 PM 6:00 PM
TEMP 21 ºC 21 ºC
5 ON 10:00 PM 10:00 PM
TEMP 14 ºC 14 ºC
Temperature
Scale: Celsius
Range: 5 ºC to 35 ºC
Resolution: 0.5 ºC
Tolerance: Less than ± 0.5 ºC at 25 ºC
Display Range: 5.0 ºC to 45.0 ºC
Display Resolution: 0.5 ºC
Setpoint Temperature Range: 5 ºC to 35 ºC
Measured Air Temperature Range: 5 ºC to 45 ºC (Displayed on LCD)
If room temp is higher than 45C,will show HI on
the LCD, if less than 5C will show LO on the LCD
Thermostat
Power Source: 2 x AA alkaline batteries
(don’t use rechargeable batteries)
RT505TX INSTRUCTION MANUAL
17
