7.5. NXE / NXEP Model
B NXE --> NXE BASE
E NXE --> NXE TOP
W
X
Y
Z
KG
NXE-20 / NXE-
20 PIZZA
1461 1912 1285 315 229/238
NXE-20 + V 1461 1912 1285 315 284
NXEP-20 1364 1912 1285 315 293
NXE-30 1561 1912 1285 415 276
NXE-30 + V 1561 1912 1285 415 323
B NXE -- 1912 1167 150 83
E NXE -- 1912 1296 165 57
7.6. NXD / NXDP Model
B NXD --> NXD BASE
E NXD --> NXD TOP
W
X
Y
Z
KG
NXD-20 2228 1912 2052 315 340
NXD-20 + V 2228 1912 2052 315 431
NXDP-20 2131 1912 2052 315 441
B NXD -- 1912 1934 150 122
E NXD -- 1912 2098 165 86
7.7. NXM Model
B NXM --> NXM BASE
E NXM --> NXM TOP
W
X
Y
Z
KG
NXM-20 / NXM-
20 PIZZA
1461 1452 1285 315 170185
NXM-20 + V 1461 1452 1285 315 220
NXM-30 1561 1452 1285 415 203
NXM-30 + V 1561 1452 1285 415 251
NXMP-20 1364 1452 1285 315 225
B NXM -- 1452 1167 150 65
E NXM -- 1452 1296 165 43
