Pos. Code Description Q. ty
8000 Larius 2 in alluminium
8199
Larius 2 in alluminium abrasive products
1 8002 Flange 2
2 8039 O ring 4
3
91641 Lower ball Ø3/4” 2
8189 Lower ball Ø3/4” abrasive products 2
4 8016 Lower ball seat 2
5
8017 Upper ball Ø9/16” 2
8188 Upper ball Ø9/16” abrasive products 2
6 8015 Upper ball seat 2
7 8040 Loer manifold 1
8 33010 Washer 4
9 32108 Plug 3/8” 2
10 8071 Washer 3
11 8108 Plug 1/2" 1
12 8058 Fitting 1/2" 2
13 8022 Supporting bracket 2
14 7043 Screw 4
15 8003 Upper manifold 1
16 8037 Screw 4
17 8020 Plug 2
18 8158 Selfocking nut 2
19 8012 Membrane pressing washer 4
20 301013 O ring 4
21
8013 PTFE membrane 2
8187 PTFE membrane
abrasive products 2
22 8014 Rubber membrane 2
Pos. Code Description Q. ty
23 8011 Washer 2
24 8007 Elastic ring 2
25 8005 O ring 2
26 8004 Seal ring seat 2
27 8006 Seal ring 2
28 8021 Pilot pad 2
29 8009 Elastic ring 2
30 8010 Elastic pin 1
31 8048 O ring 2
32 8008 Rod 1
33 8001 Pump body 1
34
8047 Screw 12
8054 Silencer 2
36 8026 Grub screw 2
37 8055 Fitting 1
38 3344 Pressure regulator 1
39 8032 "I" fitting 1
40 3338 Bayonet fitting 1
41 8031 Fitting ¼”-Ø4 1
42 8044/1 Hose 1
43 3343 Fitting 1
44 3341 Union elbow 1
45 8167 Manometer 1
46 8056 Fitting 1
47 8027 Pilot valve 1
48 8084 Screw 4
