Samoa Larius 2 Transfer - Page 13

Pos. Code Description Q. ty
8132 Larius 2 stainless steel
8232
Larius 2 stainless steel abrasive products
1 8134 Flange 2
2 8039 O ring 4
3
91641 Lower ball Ø3/4” 2
8189 Lower ball Ø3/4” abrasive products 2
4 8016 Lower ball seat 2
5
8017 Upper ball Ø9/16” 2
8188 Upper ball Ø9/16” abrasive products 2
6 8015 Upper ball seat 2
7 8043/1 Manifold 2
8 8158 Selfocking nut 2
9 8138 Membrane pressing washer 2
10 301013 O ring 4
11 8056 Fitting 1
12 8022 Supporting bracket 2
13 7043 Screw 4
14 3343 Fitting 1
15 8167 Manometer 1
16 3341 Union elbow 1
17 8027 Pilot valve 1
18 8012 Membrane pressing washer 2
19 8084 Screw 4
20
8013 PTFE membrane 2
8187 Membrane PTFE abrasive products 2
21 8014 Rubber membrane 2
22 8011 Washer 2
Pos. Code Description Q. ty
23 8007 Elastic ring 2
24 8005 O ring 2
25 8004 Seal ring seat 2
26 8006 Seal ring 2
27 8021 Pilot pad 2
28 8009 Elastic ring 2
29 8010 Elastic pin 1
30 8048 O ring 2
31 8008 Rod 1
32 8001 Pump body 1
33 8047 Screw 12
34
8054 Silencer 2
8026 Grub screw 2
36 8055 Fitting 1
37 3344 Pressure regulator 1
38 8032 "I" fitting 1
39 3338 Bayonet fitting 1
40 8031 Fitting ¼”-Ø4 1
41 8044/1 Hose 1
42 33010 Washer 4
43 8020 Plug 4
44 8037 Screw 4
45 8071 Washer 3
46 8119 Plug 1/2" 1
47 8137 Fitting 1/2" 2
48 8136 Upper manifold 1
