4.7.2.2 CUT OFF VOLT 1 (Table 4.6, Parameter Setup Screen No.2)
If during "Charging Mode", the AC input voltage falls below "CUT-OFF VOLT 1" for period > "DETECT TIME 1"(Section
4.7.2.3), the EVO™ Inverter/Charger will transfer to Inverting Mode.
4.7.2.2.1 Programming Steps for Parameter "CUT OFF VOLT 1"
Enter Key Up Key x 3 times Enter Key Up Key x 1 time Enter Key
A N Y O P E R A T I N G
M O D E S C R E E N
ð
S E L E C T G R O U P
C H A R G E C U R V E
ð
S E L E C T G R O U P
I N P U T L O W L I M I T
ð
R E S E T V O L T A G E
1 2 5 . 0 V
ð
C U T O F F V O L T 1
1 3 5 . 0 V
ð
K E Y I N P A S S W O R D
0 0 0 0
Password 8052
See Section 4.3.1
ð
C U T O F F V O L T 1
0 1 3 5 . 0 V
4.7.2.3 DETECT TIME 1 (Table 4.6, Parameter Setup Screen No.3)
This is the time limit in cycles up to which low AC input voltage "CUT-OFF VOLT 1"(Section 4.7.2.2) is allowed.
4.7.2.3.1 Programming Steps for Parameter "DETECT TIME 1"
Enter Key Up Key x 3 times Enter Key Up Key x 2 times Enter Key
A N Y O P E R A T I N G
M O D E S C R E E N
ð
S E L E C T G R O U P
C H A R G E C U R V E
ð
S E L E C T G R O U P
I N P U T L O W L I M I T
ð
R E S E T V O L T A G E
1 2 5 . 0 V
ð
D E T E C T T I M E 1
6 0 c y c l e
ð
K E Y I N P A S S W O R D
0 0 0 0
Password 8052
See Section 4.3.1
ð
D E T E C T T I M E 1
0 0 6 0 c y c l e
4.7.2.4 CUT OFF VOLT 2 (Table 4.6, Parameter Setup Screen No.4)
If during "Charging Mode", the AC input voltage falls below "CUT-OFF VOLT 2" for period > "DETECT TIME 2"(Section
4.7.2.5), the EVO™ Inverter/Charger will transfer to "Inverting Mode".
4.7.2.4.1 Programming Steps for Parameter "CUT OFF VOLT 2"
Enter Key Up Key x 3 times Enter Key Up Key x 3 times Enter Key
A N Y O P E R A T I N G
M O D E S C R E E N
ð
S E L E C T G R O U P
C H A R G E C U R V E
ð
S E L E C T G R O U P
I N P U T L O W L I M I T
ð
R E S E T V O L T A G E
1 2 5 . 0 V
ð
C U T O F F V O L T 2
1 4 0 . 0 V
ð
K E Y I N P A S S W O R D
0 0 0 0
Password 8052
See Section 4.3.1
ð
C U T O F F V O L T 2
1 4 0 . 0 V
4.7.2.5 DETECT TIME 2 (Table 4.6, Parameter Setup Screen No.5)
This is the time limit in cycles up to which low AC input voltage "CUT-OFF VOLT 2"(Section 4.7.2.4) is allowed.
4.7.2.5.1 Programming Steps for Parameter "DETECT TIME 2"
Enter Key Up Key x 3 times Enter Key Up Key x 4 times Enter Key
A N Y O P E R A T I N G
M O D E S C R E E N
ð
S E L E C T G R O U P
C H A R G E C U R V E
ð
S E L E C T G R O U P
I N P U T L O W L I M I T
ð
R E S E T V O L T A G E
1 2 5 . 0 V
ð
D E T E C T T I M E 2
1 5 c y c l e
ð
K E Y I N P A S S W O R D
0 0 0 0
Password 8052
See Section 4.3.1
ð
D E T E C T T I M E 2
0 0 1 5 c y c l e
4.7.2.6 CUT OFF VOLT 3 (Table 4.6, Parameter Setup Screen No.6)
If during "Charging Mode", the AC input voltage falls below "CUT-OFF VOLT 3" for period > "DETECT TIME 3"(Section
4.7.2.7), the EVO™ Inverter/Charger will transfer to "Inverting Mode".
4.7.2.6.1 Programming Steps for Parameter "CUT OFF VOLT 3"
Enter Key Up Key x 3 times Enter Key Up Key x 5 times Enter Key
A N Y O P E R A T I N G
M O D E S C R E E N
ð
S E L E C T G R O U P
C H A R G E C U R V E
ð
S E L E C T G R O U P
I N P U T L O W L I M I T
ð
R E S E T V O L T A G E
1 2 5 . 0 V
ð
C U T O F F V O L T 3
1 4 5 . 0 V
ð
K E Y I N P A S S W O R D
0 0 0 0
Password 8052
See Section 4.3.1
ð
C U T O F F V O L T 3
1 4 5 . 0 V
4.7.2.7 DETECT TIME 3 (Table 4.6, Parameter Setup Screen No.7)
This is the time limit in cycles up to which low AC input voltage "CUT-OFF VOLT 3"(Section 4.7.2.6) is allowed.
