SAMLEX AMERICA INC. | 61
APPENDIX A
4.7.2.7.1 Programming Steps for Parameter "DETECT TIME 3"
Enter Key Up Key x 3 times Enter Key Up Key x 6 times Enter Key
A N Y O P E R A T I N G
M O D E S C R E E N
ð
S E L E C T G R O U P
C H A R G E C U R V E
ð
S E L E C T G R O U P
I N P U T L O W L I M I T
ð
R E S E T V O L T A G E
1 2 5 . 0 V
ð
D E T E C T T I M E 3
1 c y c l e
ð
K E Y I N P A S S W O R D
0 0 0 0
Password 8052
See Section 4.3.1
ð
D E T E C T T I M E 3
0 0 0 1 c y c l e
4.8 GROUP 5 PARAMETER SET UP: OTHER FUNCTIONS
4.8.1 Programming Ranges and Default/ Factory Preset Values of Parameters Under Group 5 –
OTHER FUNCTION
Table 4.7 gives details of programming ranges and default values of parameters under Parameter Group 5 - OTHER
FUNCTION. Refer to Fig 4.2 under Section 4.1 for Menu Map for navigating through various parameters under this
Group 5.
TABLE 4.7 GROUP 5 PARAMETER SET UP: OTHER FUNCTIONS
Parameter
Setup Screen
No. for
Parameter
Group No.5
(Fig 4.2)
Parameter
Setting range Default value
EVO-
2212
EVO-
3012
EVO-
2224
EVO-
4024
EVO-
2212
EVO-
3012
EVO-
2224
EVO-
4024
1 POWER SAVING 1 = Enable 0 = Disable 0 = Disable
2 ENTER POINT 4 – 50W 6W 8W 6W 8W
3 WAKE UP POINT 5 – 50W 7W 10W 7W 10W
4 REMOTE SWITCH
0 = Button Type
1 = Switch Type
Button type
5 RELAY FUNCTION
0 = Charge/Other
1 = Normal/Fault
2 = Generator 0
3 = Generator 1
4 = Generator 2
2 = Generator 0
6 COMM ID 1 – 255 1
7 BUZZER
1 = ON
0 = OFF
1 = ON
8 DISCHARGE BEEP
1 = ON
0 = OFF
0 = OFF
9 DEFAULT RESET
0 = No
1 = Yes
0 = No
10
DATALOG DISABLE
DATALOG TIME
0 = Disable, 1 = 1 sec,
2 = 10 sec, 3 = 30 sec
4 = 1 min, 5 = 5 min, 6 = 10 min
1 = 1 sec
11 PARAMETER SAVE
0 = No
1 = Yes
0 = No
12 TEMP UNIT
0 = °C
1 = °F
0 = °C
13 PASSWORD DISABLE
0 = No
1 = Yes
0 = No
SECTION 4 | Parameter Setup
