Callouts
8
6 7
Side
Bottom
6. -15dB Pad switch – When engaged, the input level is attenuated by either -15dB to prevent
distortion or when connecting a high level signal to the INPUT jack.
7. GROUND LIFT – When the switch is engaged, the input ground (shield) is disconnected.
8. Battery Door – Install a standard 9 Volt battery by opening the battery door and attaching the
battery to the terminal connector.
