Samson Resolv sub88 User Manual

Control Functions and Indicators
SYSTEM LEVEL Up and Down
Controls
The volume control is used to adjust the amount
of level to the sub88 subwoofer. In addition,
the volume control will also control the output
level of the high-pass outputs. Therefore, if you
are using the sub88 without using the high-pass
outputs, the volume control adjusts the low fre-
quency output of the sub88. If you are using the
sub88’s internal electronic crossover to run satel-
lite speakers, then the volume control will adjust
the overall system level.
FREQUENCY
The FREQUENCY control selects the upper range
cutoff frequency of the sub88’s internal electronic
crossover with a range of 30 Hz to 200 Hz. The
sub88’s crossover provides a 12dB per octave,
Linkwitz Riley filter curve. The Sweep adjusts the
highest frequency that the sub88 will reproduce,
and at the same time, the high-pass outputs track
the selected crossover frequency as the lower
limit frequency to the satellite speakers.
PHASE Switch
The sub88 can be switched for inverted phase
operation by setting the PHASE SWITCH to the
180° (degree) position. Experiment with this
switch to provide the best blend between the
subwoofer and satellite speakers.
12
Operating the Resolv sub88
7
8
9
7
8
9
ENGLISH
12
